Heavy Duty Electric Winch - Model E4
Heavy Duty Electric Winch - Model E4
SKU:RIG-fb9aff
Rugged heavy-duty electric winch with high torque motor and automatic safety features for reliability in lifting and pulling tasks.
Regular price
$2,899.99
Regular price
Sale price
$2,899.99
Unit price
per
Initiate Order
Heavy Duty Electric Winch - Model E4
$2,899.99
Quantity: 1
Claim Your Seller Account
Heavy Duty Electric Winch - Model E4
$2,899.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Model E4 Heavy Duty Hoist is designed for rugged high-speed hoisting applications. Featuring a large drum diameter that enhances wire rope life, precision gearing with self-locking reduction, and automatic safety brake for mechanical load holding. With a regenerative electric lowering system, all-weather usability, and high torque motor, this winch ensures reliability and efficiency. Ideal for lifting and pulling, it comes with various optional equipment for customizations like controls to suit applications, groove drums, and safety features like automatic load holding drum brake. Compliant with federal procurement standards and industry-specific certifications.
Product Specifications
Specifications Controls
Lever Drum Mounted at Winch | Magnetic Remote Pushbutton
Specifications Drum 3 Layers
330 ft.
Specifications Drum Diameter
6 3/4 inches
Specifications Electrical Current
230/460-3-60
Specifications Full Drum
925 ft.
Specifications Line Speed
75 FPM
Specifications Motor
10 HP
Specifications Mounting
Horizontal Base | Inverted Ceiling | Vertical
Specifications Net Weight
560 lbs.
Specifications Optional Equipment
Controls to suit application | Grooved drums | Overspeed automatic load holding drum brake and electric shut-off | Electric Motor Brake (recommended for all hoisting applications) | Two or more wire ropes off the drum | Slack Line Limit Switch | Travel Limit Switch | Cable Drum Pressure Roller - assists multiple layer reeving evenly onto drum | Mechanical Torque Limiter - automatic reset
Specifications Running Capacity Lbs
3000
Specifications Standard Wire Rope Diameter
3/8 inches
Specifications Winch Height
17 inches
Specifications Winch Length
51 inches
Specifications Winch Width
24 inches
Specifications Winch Will Be Used For
Electrical Brake Required | Lifting | Pulling
Standard Features 0
Ideal for long lift high speed hoisting applications Drum large diameter increases wire rope life Precision gearing self-locking reduction oil bath lubricated Safety brake automatic mechanical load holding type Regenerative lowering electrically retarded lowering speed Totally enclosed motor high torque hoist duty motor starting capacity is minimum two (2) times running All weather use is ideal for rugged model E4 winches minimum 5 to 1structural safety factor
