Heavy Duty Electric Winch - Model E5
Heavy Duty Electric Winch - Model E5
SKU:RIG-b6dc48
High-torque Model E5 Electric Winch with 50 HP motor, 20000 lb capacity, and durable construction for lifting and pulling tasks.
Regular price
$8,999.99
Regular price
Sale price
$8,999.99
Unit price
per
Initiate Order
Heavy Duty Electric Winch - Model E5
$8,999.99
Quantity: 1
Claim Your Seller Account
Heavy Duty Electric Winch - Model E5
$8,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Model E5 Heavy Duty Industrial Pullers are designed for high-torque applications, featuring a 50 HP motor with a totally enclosed design for crane and hoist duty. With a capacity of 20000 full load and a line speed of 45 FPM, this winch is ideal for lifting and pulling tasks. The winch includes standard features like triple reduction self-locking gearing, heavy-duty roller bearing assemblies, and a 5 to 1 structural safety factor. Its all-weather rugged construction, large diameter drums, and steel fabricated base ensure durability and long wire rope life. Optional equipment includes overspeed automatic load holding drum brake and electric shut-off, making it a versatile choice for various applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Capacity Full Load Running
20000
Specifications Controls
Lever Drum Mounted at Winch | Magnetic Remote Pushbutton
Specifications Drum Diameter
18 inches
Specifications Full Drum
950 ft.
Specifications Line Speed
45 FPM
Specifications Motor
50 HP
Specifications Mounting
Horizontal Base | Inverted Ceiling | Vertical
Specifications Net Weight
7250 lbs.
Specifications Optional Equipment
Overspeed automatic load holding drum brake and electric shut-off | Free Spooling Drum - has adjustable drag brake | Torque Limiter Mechanical Clutch - automatically resets when excessive pull is released | Cable Drum Pressure Roller - assists multiple layer reeving, keeps wire taut on drum when free spooling or when slack line occurs
Specifications Winch Height
56 inches
Specifications Winch Length
86 inches
Specifications Winch Width
63 inches
Specifications Winch Will Be Used For
Electrical Brake Required | Lifting | Pulling
Specifications Wire Rope Capacity 3 Layers
425 ft.
Specifications Wire Rope Size
7/8 inches
Standard Features 0
Totally enclosed motor high torque crane and hoist duty motor starting capacity is minimum two (2) times runningPower transmission triple reduction self locking gearingDrum support bearings heavy duty roller bearing assemblies All weather use is ideal for rugged model E5 puller winchLarge diameter drums increases wire rope life All steel fabricated winch base and drum for maximum durability minimum 5 to 1 structural safety factor
