Heavy-Duty ERP Rope Puller
Heavy-Duty ERP Rope Puller
SKU:RIG-84cd36
Rugged ERP Rope Puller for precise and reliable car pulling. 30 HP motor, high torque, and weatherproof design.
Regular price
$13,499.00
Regular price
Sale price
$13,499.00
Unit price
per
Initiate Order
Heavy-Duty ERP Rope Puller
$13,499.00
Quantity: 1
Claim Your Seller Account
Heavy-Duty ERP Rope Puller
$13,499.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Heavy-Duty ERP Rope Puller is a rugged and reliable solution designed for long-distance car pulling or fixed closed-loop hoisting. With a starting capacity of 30,000 lbs. and running capacity of 15,000 lbs., this puller ensures controlled pulling, stopping, and spotting. Its totally enclosed high torque motor provides constant speed and torque in all weather conditions. Featuring a 30 HP electric motor, steel drum, and base with a 5 to 1 safety factor, this puller guarantees durability and performance. Ideal for institutional and government applications where precision and reliability are paramount.
Product Specifications
Specifications Capacity Running
15000 lbs.
Specifications Capacity Starting
30000 lbs.
Specifications Line Speed
50 FPM
Specifications Model
ERP Continuous Rope Puller
Specifications Motor 230460 3 60 Electric
30 HP
Specifications Net Weight
11850 lbs.
Specifications Winch Height
62 inches
Specifications Winch Length
128 inches
Specifications Winch Width
64 inches
Specifications Wire Rope Size
1 inches
Standard Features 0
Totally enclosed motor high torque hoist duty Distance unlimited constant speed, constant torque All weather use is ideal for rugged model erp continuous puller Controlled pulling, stopping and spotting Counterweight not required positive traction Mounting at any convenient location Ideally suited for long distance car pulling or fixed closed loop hoisting Rope leads from one side or single lead from opposite sides of drum All steel drum and base for maximum durability minimum 5 to 1 structural safety factor.
