Heavy Duty Female Non Return Valve BSP Parallel 1 1/4
Heavy Duty Female Non Return Valve BSP Parallel 1 1/4
SKU:VAL-26b410
High-pressure Non Return Valve for hydraulic systems, Stainless Steel, DIN Valve compatible, prevents backflow
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
Heavy Duty Female Non Return Valve BSP Parallel 1 1/4
$45.99
Quantity: 1
Claim Your Seller Account
Heavy Duty Female Non Return Valve BSP Parallel 1 1/4
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Heavy Duty Female Non Return Valve BSP Parallel is designed for high-pressure hydraulic systems, with a Nominal Operating Pressure of 250 bar. Made of durable Stainless Steel, it features precise dimensions (L1: 142mm, L2: 23.5mm, CH1: 70mm) ensuring reliable performance. Ideal for DIN Valve applications, this valve guarantees secure flow control and prevents backflow, meeting stringent industry standards.
Product Specifications
Specifications Ch1
70 mm
Specifications Diameter Pass
29 mm
Specifications G Thread Size
1 1/4
Specifications L1
142 mm
Specifications L2
23.5 mm
Specifications Material
Stainless Steel
Specifications Nominal Operating Pressure
250 bar
Specifications Pressure
Heavy Duty
