Heavy Duty Foot Operated Hydraulic Pump - FPAC-LR & FPAC-PL Series
Heavy Duty Foot Operated Hydraulic Pump - FPAC-LR & FPAC-PL Series
SKU:HYD-7d22a8
Versatile and reliable foot-operated hydraulic pump for precise control and high performance in hydraulic systems without reservoirs.
Regular price
$799.99
Regular price
Sale price
$799.99
Unit price
per
Initiate Order
Heavy Duty Foot Operated Hydraulic Pump - FPAC-LR & FPAC-PL Series
$799.99
Quantity: 1
Claim Your Seller Account
Heavy Duty Foot Operated Hydraulic Pump - FPAC-LR & FPAC-PL Series
$799.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Heavy Duty Foot Operated Hydraulic Pump from the FPAC-LR & FPAC-PL Series is a versatile and reliable manual pump designed for use in hydraulic systems without reservoirs. It features adjustable overload and manual pressure release valves, offering precise control over hydraulic pressure. With options for base or flange mounting, stainless steel versions, and various pressure release mechanisms, this pump is customizable to meet diverse institutional procurement needs. Built for durability and performance, this pump delivers pressures up to 10,000 PSI, making it ideal for industrial applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Adjustable Overload Relief Valve
Yes
Specifications Body Material
Steel
Specifications Foot Lever Load Per 100 Psi
37.0 lb
Specifications Inlet Port Size Nptf
3/8
Specifications List Price
666 USD
Specifications Manual Pressure Release Valve
Yes
Specifications Maximum Pressure Rating
250 psi
Specifications Mounting
Base Mounted
Specifications Net Weight
16 lb
Specifications Oil Reservoir
false
Specifications Operating Lever Size
24 in
Specifications Outlet Port Size Nptf
3/8
Specifications Piston
Hard Chrome Plated
Specifications Piston Diameter
2 in
Specifications Series
FP-LR
Specifications Volume Per Stroke
4.71 in³
Technical Information 0
Limited WarrantyAll Star pumps are covered by a limited warranty on materials and workmanship for one year from the date of manufacture. Star will repair or replace at its option any pump in which Star finds manufacturing defects. In order to get warranty service a pump must be returned to the Star plant freight prepaid with a written explanation of the problem.Technical DataLight hydraulic oil is recommended for use with Star pumps. Oils with SUS viscosity of 75 to 150 at 100 degrees Fahrenheit will give satisfactory performance (ISO grade 15, 22, or 32). In an emergency situation when the above oils are not available, use 5 W or 10 W motor oil or automatic transmission fluid.All exposed surfaces of standard Star pumps are painted with one coat of industrial quality paint. Pumps painted with special colors with two coat finishes, or with prime coat only, and pumps with special plated or polished parts, are also available.
