Heavy-Duty Foot Operated Hydraulic Pumps - FPAC-LR & FPAC-PL Series
Heavy-Duty Foot Operated Hydraulic Pumps - FPAC-LR & FPAC-PL Series
SKU:HYD-8c08d9
Enhance efficiency in hydraulic systems with our Heavy-Duty Foot Operated Hydraulic Pumps. Adjustable overload relief valve & manual pressure release valve, pressures up to 10,000 PSI.
Regular price
$603.00
Regular price
Sale price
$603.00
Unit price
per
Initiate Order
Heavy-Duty Foot Operated Hydraulic Pumps - FPAC-LR & FPAC-PL Series
$603.00
Quantity: 1
Claim Your Seller Account
Heavy-Duty Foot Operated Hydraulic Pumps - FPAC-LR & FPAC-PL Series
$603.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance efficiency in hydraulic systems with our Heavy-Duty Foot Operated Hydraulic Pumps. Designed for compatibility with hydraulic systems featuring built-in reservoirs, these single-piston pumps come with an adjustable overload relief valve and manual pressure release valve. Offering pressures up to 10,000 PSI, choose from various mounting options, including base or flange mount. Constructed with hard chrome plated pistons, these pumps are ideal for industrial settings requiring reliable performance.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Adjustable Overload Relief Valve
Yes
Specifications Body Material
Steel
Specifications Foot Lever Load Per 100 Psi
2.3 lb
Specifications Inlet Port Size Nptf
3/8
Specifications List Price
603 USD
Specifications Manual Pressure Release Valve
Yes
Specifications Maximum Pressure Rating
5000 psi
Specifications Mounting
Base Mounted
Specifications Net Weight
15 lb
Specifications Oil Reservoir
false
Specifications Operating Lever Size
24 in
Specifications Outlet Port Size Nptf
3/8
Specifications Piston
Hard Chrome Plated
Specifications Piston Diameter
1/2 in
Specifications Series
FP-LR
Specifications Volume Per Stroke
0.29 in³
Technical Information 0
Limited WarrantyAll Star pumps are covered by a limited warranty on materials and workmanship for one year from the date of manufacture. Star will repair or replace at its option any pump in which Star finds manufacturing defects. In order to get warranty service a pump must be returned to the Star plant freight prepaid with a written explanation of the problem.Technical DataLight hydraulic oil is recommended for use with Star pumps. Oils with SUS viscosity of 75 to 150 at 100 degrees Fahrenheit will give satisfactory performance (ISO grade 15, 22, or 32). In an emergency situation when the above oils are not available, use 5 W or 10 W motor oil or automatic transmission fluid.All exposed surfaces of standard Star pumps are painted with one coat of industrial quality paint. Pumps painted with special colors with two coat finishes, or with prime coat only, and pumps with special plated or polished parts, are also available.
