Heavy Duty I Beam Festoon System - Series 450 Running Gear for W Beams

Name: Heavy Duty I Beam Festoon System - Series 450 Running Gear for W Beams
Brand: Clutch Engineering
SKU: CRA-b42820
Price: 499.99 USD
Availability: OutOfStock

SKU:CRA-b42820

Durable Series 450 Running Gear for W Beams with steel main rollers, polyurethane tires, and horizontal guide rollers for efficient crane control. Maximum load 315 lb.

$499.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Series 450 Running Gear for W Beams is a robust solution designed for crane control and electrification applications. Crafted with durable materials, it features steel main rollers, polyurethane tires, and horizontal guide rollers for smooth and efficient operations. With a maximum load capacity of 315 lb and a speed of 500 fpm, this running gear ensures reliable performance in challenging environments. The galvanized steel spacers, stainless steel fasteners, and hardened steel components guarantee longevity and corrosion resistance. Ideal for heavy-duty industrial settings, this running gear offers easy maintenance with independent side shield removal capabilities.

Product Specifications

Specifications Beam Size

W8 x 13 in

Specifications Main Roller Diameter

2.5 in | 62 mm

Specifications Maximum Load

315 lb | 143 kg

Specifications Operating Temperature

-22 to 220 ÂºF

Specifications Running Gear Type

Steel Main Rollers, Polyurethane Tire, with Horizontal Guide Rollers

Specifications Speed

500 fpm

Specifications Weight

23.3 lb | 10.6 kg
