The Heavy-Duty Multi-Way Cable Pulling Harness is a robust solution designed to facilitate efficient and secure cable pulling operations. With a working load capacity of 4200 lb. combined, this harness features 6 legs with a working load of 1400 lb. per leg. The design includes a max width of 3.75 inches and a separation between legs of 14 inches, ensuring stability and performance. The lead ring diameter of 0.63 inches and leg diameter of 0.25 inches provide durability and strength. Ideal for heavy-duty applications, this harness offers exceptional reliability and ease of use, meeting the stringent requirements of government and institutional procurement standards.
Product Specifications
Specifications Lead Ring Diameter C In
0.63
Specifications Lead Ring Diameter C Mm
16
Specifications Leg Diameter D In
0.25
Specifications Leg Diameter D Mm
6
Specifications Max Width A In
3.75
Specifications Max Width A Mm
95
Specifications Note
10 & 12 Way 3/8" (10 mm) harnesses only have a single stagger. All other harnesses are sequentially staggered.
Specifications Separation Between Legs B In
14
Specifications Separation Between Legs B Mm
356
Specifications Working Load Combined Lb
4200
Specifications Working Load Combined N
18683
Specifications Working Load Per Leg Lb
1400
Specifications Working Load Per Leg N
6228
