Heavy-Duty Single Vertical Sheave Assemblies
Heavy-Duty Single Vertical Sheave Assemblies
SKU:RIG-4a8381
Durable, high-capacity single sheave assemblies for efficient lifting and pulling applications. Compact design with versatile mounting options.
Regular price
$599.99
Regular price
Sale price
$599.99
Unit price
per
Initiate Order
Heavy-Duty Single Vertical Sheave Assemblies
$599.99
Quantity: 1
Claim Your Seller Account
Heavy-Duty Single Vertical Sheave Assemblies
$599.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Our Heavy-Duty Single Vertical Sheave Assemblies, model SVS, are designed for high-capacity needs, with a 4000 lbs. capacity and 7/16 inches wire rope diameter. These assemblies boast a compact design with dimensions perfect for various mounting options including horizontal base, inverted ceiling, and vertical for efficient usage. The controls feature a lever drum mounted at the winch and a magnetic remote pushbutton for convenient operation. Ideal for lifting and pulling applications, our sheave assemblies ensure reliable performance and durability in demanding environments.
Product Specifications
Specifications Capacity
4000 lbs.
Specifications Controls
Lever Drum Mounted at Winch | Magnetic Remote Pushbutton
Specifications Dimension A
10 3/4 inches
Specifications Dimension B
8 inches
Specifications Dimension C
8 inches
Specifications Dimension D
6 inches
Specifications Dimension E
5 1/2 inches
Specifications Dimension F
5/8 inches
Specifications Dimension H
7/8 inches
Specifications Model
SVS
Specifications Mounting
Horizontal Base | Inverted Ceiling | Vertical
Specifications Pitch Diameter
6 inches
Specifications Winch Will Be Used For
Electrical Brake Required | Lifting | Pulling
Specifications Wire Rope Diameter
7/16 inches
