The Heavy-Duty Two-Way Link Chain Pulling Harness is a robust solution designed for industrial and commercial applications requiring simultaneous pulling from multiple points. With a maximum working load of 3500 lb per leg and 15000 lb combined, this harness offers superior strength and durability. The 3.50-inch width, 14-inch separation between legs, and 0.31-inch leg diameter ensure stability and balance during heavy-duty pulling tasks. Notably, this harness meets stringent government procurement standards and is ideal for projects requiring precision and reliability.
Product Specifications
Specifications Lead Ring Diameter C In
0.50
Specifications Lead Ring Diameter C Mm
13
Specifications Leg Diameter D In
0.31
Specifications Leg Diameter D Mm
8
Specifications Max Width A In
3.50
Specifications Max Width A Mm
89
Specifications Note
10 & 12 Way 3/8" (10 mm) harnesses only have a single stagger. All other harnesses are sequentially staggered.
Specifications Separation Between Legs B In
14
Specifications Separation Between Legs B Mm
356
Specifications Working Load Combined Lb
15000
Specifications Working Load Combined N
22240
Specifications Working Load Per Leg Lb
3500
Specifications Working Load Per Leg N
15568
