HepcoMotion Single Edge Curved Ring Slide for TNME Tracks
HepcoMotion Single Edge Curved Ring Slide for TNME Tracks
SKU:ATL-a6be1d
Enhance your TNME track system with the precision-engineered HepcoMotion Single Edge Curved Ring Slide for seamless performance.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
HepcoMotion Single Edge Curved Ring Slide for TNME Tracks
$59.99
Quantity: 1
Claim Your Seller Account
HepcoMotion Single Edge Curved Ring Slide for TNME Tracks
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The HepcoMotion Single Edge Curved Ring Slide is designed for precision performance in TNME track systems. Made to True Shape specification, these segments are meticulously crafted to match straight slides, ensuring seamless integration. With essential features like ground square ends, extra fixing holes for added support, and gear cut options for gear-driven systems, these curved segments are marked for easy identification and replacement. Align to perfection with machined register compatibility. Upgrade your track system with these high-quality HepcoMotion Ring Slides.
Product Specifications
Specifications Circuit
DPDT-SNAP ACTION
Specifications Constructionstandards
NEMA Type 1, 2, 4, 6, 6P & 13UL Enclosure 1, 2, 4, 6, 6P & 13EN 60529 Degree of Protection IP68IEC 601-2-2
Specifications Electrical Rating
A300, Q300 : lth = 10A (AC) | A300, Q300 : lth = 2.5A (DC) | AC15 : Ue = 240V; le = 3A | AC15 : Ue = 120V; le = 6A | DC 13 : Ue = 250V; le = 0.27A | DC 13 : Ue = 120V; le = 0.55A | DC 13 : Ue = 24V; le = 2.5A
Specifications Features
DriptightDusttightWatertightOiltight
Specifications Note
"OX" Shield - Anti Trip, "O" Shield - Hercules and Full Shield - Atlas. These three types of shields are available.
Specifications Size
9 x 6 x 5 1/2 Inch
Specifications Weight Approx
4 1/2 lbs
