Hermetic Seal Male SMA Connector

Name: Hermetic Seal Male SMA Connector
Brand: C. W. Swift & Associates, Inc.
SKU: SMA-2d2f52
Price: 29.99 USD
Availability: OutOfStock

SKU:SMA-2d2f52

Precision-engineered Hermetic Seal Male SMA Connector for reliable signal transmission in critical environments.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Hermetic Seal Male SMA Connector is a precision-engineered solution designed for critical applications requiring reliable signal transmission. This connector features a hermetic seal with precision glass to metal soldering, ensuring optimal performance even in harsh environments. With a frequency range of DC - 18 GHz, impedance of 50 ohms, and gold-plated body for enhanced durability, this connector meets the highest industry standards for signal integrity and longevity. The 290 psi maximum pressure rating further enhances its reliability under challenging conditions.

Product Specifications

Specifications Cable Dielectic Dia Inches

.066/.117

Specifications Configuration

hermetic seal receptacle

Specifications Connection

male

Specifications Connector Series

SMA

Specifications Frequency Range Ghz

DC - 18

Specifications Impedence Ohms

Specifications Notes

290 psi max. press.

Specifications Packaging

single

Specifications Plating Body

gold

Hermetic Seal Male SMA Connector
