Hermetic Seal SMA Connector Receptacle - Gold Plated, Male

Name: Hermetic Seal SMA Connector Receptacle - Gold Plated, Male
Brand: C. W. Swift & Associates, Inc.
SKU: SMA-ea514b
Price: 24.99 USD
Availability: OutOfStock

SKU:SMA-ea514b

Precision Hermetic Seal SMA Connector Receptacle, gold-plated male connector for optimal signal integrity and durability.

$24.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Hermetic Seal SMA Connector Receptacle features precision glass to metal seals soldered into the connector body, ensuring optimal signal integrity and durability. With a cable dielectric diameter of .066/.117 inches, impedance of 50 ohms, and a frequency range of DC - 18 GHz, this connector is ideal for high-performance applications. The gold-plated body and hermetic seal configuration provide excellent protection against environmental factors, while the male connection type and mounting hole design further enhance its reliability. Meeting industry standards for 290 psi maximum pressure, this SMA connector guarantees secure and reliable connections in demanding environments.

Product Specifications

Specifications Cable Dielectic Dia Inches

.066/.117

Specifications Configuration

hermetic seal receptacle

Specifications Connection

male

Specifications Connector Series

SMA

Specifications Frequency Range Ghz

DC - 18

Specifications Impedence Ohms

Specifications Mounting Hole

ML 98

Specifications Notes

290 psi max. press.

Specifications Packaging

single

Specifications Plating Body

gold

Hermetic Seal SMA Connector Receptacle - Gold Plated, Male
