Hermetic Seal SMA Female Receptacle
Hermetic Seal SMA Female Receptacle
SKU:SMA-c281be
High-performance Hermetic Seal SMA Female Receptacle for secure, durable connections in high-pressure environments.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Hermetic Seal SMA Female Receptacle
$29.99
Quantity: 1
Claim Your Seller Account
Hermetic Seal SMA Female Receptacle
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Hermetic Seal SMA Female Receptacle features precision glass-to-metal seals integrated into the connector body, ensuring optimal performance and durability. With a gold-plated body and a frequency range of DC-18GHz, this connector provides secure connections and superior conductivity. Ideal for applications requiring high-pressure tolerance (up to 290 psi), this SMA connector ensures reliable signal transmission in demanding environments.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Cable Dielectic Dia Inches
.066/.117
Specifications Configuration
hermetic seal receptacle
Specifications Connection
male
Specifications Connector Series
SMA
Specifications Frequency Range Ghz
DC - 18
Specifications Impedence Ohms
50
Specifications Mounting Hole
ML 42
Specifications Notes
290 psi max. press.
Specifications Packaging
single
Specifications Plating Body
gold
