Hermetically Sealed Low Level Audio Input Transformer - Triad HS Series
Hermetically Sealed Low Level Audio Input Transformer - Triad HS Series
SKU:AUD-ce9fcf
Experience premium audio performance and reliability with the Hermetically Sealed Low Level Audio Transformer from the Triad HS Series.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
Hermetically Sealed Low Level Audio Input Transformer - Triad HS Series
$89.99
Quantity: 1
Claim Your Seller Account
Hermetically Sealed Low Level Audio Input Transformer - Triad HS Series
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Hermetically Sealed Low Level Audio Input Transformer from the Triad HS Series sets the standard for audio equipment manufacturers. With a frequency response range of 20 to 20000 Hz, and up to 95 dB of shielding, these transformers excel in performance and durability. Designed to MIL-T-27 specifications, these transformers feature multiple 'Trialloy' cases, heavy copper shading rings, and are 'Climatite' treated for longevity. Perfect for applications requiring balanced center tap impedance, these transformers ensure unmatched performance and reliability for military and industrial use.
Product Specifications
Additional Information Additional Information
Avoid redesign - Use Triad HS and HSM transformers in military prototypesTriad HS and HSM series transformers are designed to meet MIL-T-27 requirements. Most of these transformers use standard MIL-T-27 case sizes. Exceptions are GP cases or any cases showing a Bw dimension, which may be classified as MIL-T-27 'YY' cases. Equipment using these transformers need not be redesigned to submit for military approval. The basically good design factors which are necessary to meet MIL-T-27 standards for performance ensure longest life in any class of service.These transformers are permanently marked with electrical and test data as specified in MIL-T-27. All are "Climatite" treated, use sturdy TRIAD terminals and are beautifully finished in gray enamel.
Electrical Specifications At 25 Degree Celsius C Temperature Max
20 dBu
Electrical Specifications At 25 Degree Celsius C Temperature Ove
1:14
Electrical Specifications At 25 Degree Celsius C Temperature Pri
62.5 Ohm | 150 Ohm | 250 Ohm | 600 Ohm
Electrical Specifications At 25 Degree Celsius C Temperature Sec
117600 Ohm
Note Note
Low frequency loss will result from unbalanced DC in windings other than where specified.
Specifications Applications
Line to P. P. Class A Grids-Hi Level.
Specifications Case
GP-4
Specifications Frequency Response Range
20 to 20000 Hz
Specifications Note For Primary Impedance
Balanced Center Tap. (600 and 250 Ohm)
Specifications Note For Secondary Impedance
Center Tap
Specifications Shielding
P-1 - One nickel alloy high permeability shield - 45 db. reduction in pickup.
