Hermetically Sealed Low Level Audio Input Transformer - Triad HS Series
Hermetically Sealed Low Level Audio Input Transformer - Triad HS Series
SKU:AUD-306f4a
Enhance audio equipment with the Hermetically Sealed Low Level Audio Input Transformer. Unmatched performance in a compact size.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
Hermetically Sealed Low Level Audio Input Transformer - Triad HS Series
$129.99
Quantity: 1
Claim Your Seller Account
Hermetically Sealed Low Level Audio Input Transformer - Triad HS Series
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Hermetically Sealed Low Level Audio Input Transformer from the Triad HS Series sets the standard for exceptional audio equipment performance. With a wide frequency range of 20 to 20000 Hz, this transformer offers superior magnetic shielding up to 95 dB, achieved through multiple 'Trialloy' cases interleaved with heavy copper shading rings. Meeting MIL-T-27 specifications, it features a balanced center tap primary impedance of 600 and 250 Ohm, ensuring unmatched performance, longevity, and compact size. Ideal for universal line or microphone to grid applications, this transformer boasts rigid construction, welded stainless steel studs, and climatite treatment for durability.
Product Specifications
Additional Information Additional Information
Avoid redesign - Use Triad HS and HSM transformers in military prototypesTriad HS and HSM series transformers are designed to meet MIL-T-27 requirements. Most of these transformers use standard MIL-T-27 case sizes. Exceptions are GP cases or any cases showing a Bw dimension, which may be classified as MIL-T-27 'YY' cases. Equipment using these transformers need not be redesigned to submit for military approval. The basically good design factors which are necessary to meet MIL-T-27 standards for performance ensure longest life in any class of service.These transformers are permanently marked with electrical and test data as specified in MIL-T-27. All are "Climatite" treated, use sturdy TRIAD terminals and are beautifully finished in gray enamel.
Electrical Specifications At 25 Degree Celsius C Temperature Max
10 dBu
Electrical Specifications At 25 Degree Celsius C Temperature Ove
1:11.3
Electrical Specifications At 25 Degree Celsius C Temperature Pri
62.5 Ohm | 150 Ohm | 250 Ohm | 600 Ohm
Electrical Specifications At 25 Degree Celsius C Temperature Sec
77000 Ohm
Note Note
Low frequency loss will result from unbalanced DC in windings other than where specified.
Specifications Applications
Universal Line or Mike to Grid.
Specifications Case
GP-4
Specifications Frequency Response Range
20 to 20000 Hz
Specifications Note For Primary Impedance
Balanced Center Tap. (600 and 250 Ohm)
Specifications Shielding
P-5 - Three nickel alloy shields interleaved with two heavy copper shading rings - 95 db. reduction in pickup.
