Hermetically Sealed Low Level Audio Interstage Transformer
Hermetically Sealed Low Level Audio Interstage Transformer
SKU:AUD-f9e745
Triad Hermetically Sealed Low Level Audio Interstage Transformer - Unmatched performance, wide frequency range, and exceptional magnetic shielding for superior audio quality.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
Hermetically Sealed Low Level Audio Interstage Transformer
$129.99
Quantity: 1
Claim Your Seller Account
Hermetically Sealed Low Level Audio Interstage Transformer
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Hermetically Sealed Low Level Audio Interstage Transformer from Triad sets the standard in audio equipment manufacturing. Featuring a wide frequency range of 20 to 20000 Hz, this transformer offers outstanding magnetic shielding with up to 95 dB reduction. Built to MIL-T-27 specifications, it boasts a durable construction with welded stainless steel studs and is hermetically sealed. With primary impedance options of 5000 Ohm and 20000 Ohm, secondary impedance of 60000 Ohm, and a maximum input level of 50 dBu, this transformer ensures top-notch performance and longevity. Perfect for applications like P. P. Plates to P. P. Class A Grids, it excels in both appearance and functionality.
Product Specifications
Additional Information Additional Information
Avoid redesign - Use Triad HS and HSM transformers in military prototypesTriad HS and HSM series transformers are designed to meet MIL-T-27 requirements. Most of these transformers use standard MIL-T-27 case sizes. Exceptions are GP cases or any cases showing a Bw dimension, which may be classified as MIL-T-27 'YY' cases. Equipment using these transformers need not be redesigned to submit for military approval. The basically good design factors which are necessary to meet MIL-T-27 standards for performance ensure longest life in any class of service.These transformers are permanently marked with electrical and test data as specified in MIL-T-27. All are "Climatite" treated, use sturdy TRIAD terminals and are beautifully finished in gray enamel.
Electrical Specifications At 25 Degree Celsius C Temperature Max
50 dBu
Electrical Specifications At 25 Degree Celsius C Temperature Ove
1:2.72
Electrical Specifications At 25 Degree Celsius C Temperature Pri
5000 Ohm | 20000 Ohm
Electrical Specifications At 25 Degree Celsius C Temperature Sec
60000 Ohm
Note Note
Low frequency loss will result from unbalanced DC in windings other than where specified.
Specifications Applications
P. P. Plates to P. P. Class A Grids.
Specifications Case
GP-4
Specifications Frequency Response Range
20 to 20000 Hz
Specifications Note For Secondary Impedance
Center Tap
Specifications Shielding
P-1 - One nickel alloy high permeability shield - 45 db. reduction in pickup.
