Hevi-Bar II Standard Expansion Section
Hevi-Bar II Standard Expansion Section
SKU:CRA-c0d96a
Enhance structural joints with the Hevi-Bar II Standard Expansion Section. Durable polycarbonate construction, 1500A, indoor/outdoor use.
Regular price
$599.99
Regular price
Sale price
$599.99
Unit price
per
Initiate Order
Hevi-Bar II Standard Expansion Section
$599.99
Quantity: 1
Claim Your Seller Account
Hevi-Bar II Standard Expansion Section
$599.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Hevi-Bar II Standard Expansion Section is a vital component for structural expansion joints and systems exceeding 390 ft. It features a durable polycarbonate construction with an Amperage Rating of 1500 A, suitable for both indoor and outdoor use. With a Maximum Temperature of 250 °F, this expansion section ensures reliable performance in various environments. Included accessories like the thermostatically controlled heater wire system and Transfer Caps enhance functionality, making it ideal for crane control and electrification applications.
Product Specifications
Specifications Amperage Rating
1500 A
Specifications Cover Type
Phase & Ground/ Indoors & Outdoors (Red)
Specifications Length
20.0 ft
Specifications Material
Polycarbonate
Specifications Maximum Temperature
250 ºF
Specifications Weight
88.0 lb
