High Carbon Steel Twisted Power Tube Brush - 5/16in Diameter
High Carbon Steel Twisted Power Tube Brush - 5/16in Diameter
SKU:TWI-910e5d
High Carbon Steel Twisted Power Tube Brush for heavy-duty cleaning tasks with 5/16in diameter. Double stem design for enhanced strength and durability.
Regular price
$14.99
Regular price
Sale price
$14.99
Unit price
per
Initiate Order
High Carbon Steel Twisted Power Tube Brush - 5/16in Diameter
$14.99
Quantity: 1
Claim Your Seller Account
High Carbon Steel Twisted Power Tube Brush - 5/16in Diameter
$14.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The High Carbon Steel Twisted Power Tube Brush features a 5/16in brush diameter with a 0.005in filament diameter, ideal for polishing, blending, burr removal, and heavy-duty cleaning tasks. With a double stem, double spiral design and cut-off end, this brush delivers exceptional strength and durability. The twisted brush stem construction enhances density fill and ensures effective performance. Operating at recommended speeds of 100-500 RPM, this brush minimizes stem deflections and bending. Explore various filament and wire options for tailored applications. Order additional sizes upon request for comprehensive cleaning solutions.
Product Specifications
Before Starting The Twist Brush Rotation
Secure the brush in the chuck.Ensure clockwise brush rotation-counter clockwise rotation can cause the brush to come apart and release the filament.Securely clamp the workpiece. Make sure all machine guards are in position.Align the brush with the workpiece to ensure the brush rotates on its true center line and avoid stem deflection.Guide the brush into the hole before starting the brush rotation.Always wear eye protection and protective clothing!
Note
Other sizes are available upon request.
Operating Recommendations
When mounting a twisted brush in a collet or chuck, it is recommended to minimize the overhang of the stem to under an inch. This is particularly true with power tube brushes, and it is important to avoid any load conditions and operating speeds that can cause stem deflections and destructive bending. A safe operating speed from 100-500 RPM is recommended for most twisted brushes.To reach into deeper holes we recommend the use of collet-ready shank mounted brushes or drill extension rods rather than increasing stem overhang.
Other Considerations
Wire OptionsCoatedGalvanizedStainless SteelFilament OptionsAbrasive NylonCeramiX®BrassCarbon SteelHorse HairNylonStainless SteelCrimped, Level or Color OptionsGaugeStem DiameterOtherShank TypeTubingCouplingLoopNo Loop
Specifications Brush Diameter
5/16 in
Specifications Brush Length
1-1/2 in
Specifications Brush Tip Styles
Continuous End | Cut Off End
Specifications Filament Diameter
0.005 in
Specifications Fill Material
High Carbon Steel
Specifications Overall Length
4 in
Specifications Stem Diameter
0.125 in
Twisted Brush Stem Construction
Filament is twisted between four stem wires, with two stem wires on each side for additional strength and higher density fill.
