High Current Flash Lamp Connector - Single Ended 4mm Molded Plug
High Current Flash Lamp Connector - Single Ended 4mm Molded Plug
SKU:HIG-aa34d5
High Current Flash Lamp Connector with 12 kV DC Voltage & 75 A Current Rating, ideal for space-sensitive applications.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
High Current Flash Lamp Connector - Single Ended 4mm Molded Plug
$24.99
Quantity: 1
Claim Your Seller Account
High Current Flash Lamp Connector - Single Ended 4mm Molded Plug
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The High Current Flash Lamp Connector features 'Multilam band' contact spring finger technology for superior current ratings and lower temperature rise. With a Direct Current (DC) Voltage of 12 kV and a Current Rating of 75 A, this connector is ideal for applications requiring high reliability under demanding conditions. Made with Tellurium Copper Alloy and Beryllium Copper Alloy materials, it guarantees efficient performance in a temperature range from -40°C to +175°C. The over molded strain relief with Silicone Rubber ensures durability and safety in operation, making it a cost-effective solution for space-sensitive environments.
Product Specifications
Applications 0
LaserBack Lighting & IlluminationPercussion
Ordering Information 0
Flash lamp plugs can be ordered as single ended or double ended assemblies in any combination of molded plug or socket contact at each end. Consult factory for custom configuration part numbers.Flash lamp contacts can be ordered with or without wire terminated. connectronics offers a variety of wire constructions for use with flash lamp contacts. Consult factory for additional information.
Specifications Contact Body Material
Tellurium Copper Alloy 145, Silver Plated Per qq-s-365
Specifications Current Rating
75 A
Specifications Direct Current Dc Voltage
12 kV
Specifications Features
High Current RatingsOperating Voltage: through 12 KVDCTemperature Range: -40°C to +175°CSea Level to 10,000 ft OperationOvermolded Strain Relief available4mm, 5mm, 5.5mm and 6mm optionsStackable or Threaded options
Specifications Length L
40 in
Specifications Molded Strain Relief Material
Silicone Rubber, Gray
Specifications Multi Lam Contact Band Spring Fingers Material
Beryllium Copper Alloy, Gold Plated Per MIL-G-45204
Specifications Sea Level Altitude
0 to 10,000 ft
Specifications Size
4 mm | 0.157 in
Specifications Wirecable Material
Assemblies supplied with wire are terminated with #12; AWG (19/25; SPC conductor with silicone insulation rated for 20 KVDC (0.205 dia.) 1 REF. connectronics part no . 066-035-01.
