High Fidelity 1740 Ohm Primary DC Resistance Audio Transformer
High Fidelity 1740 Ohm Primary DC Resistance Audio Transformer
SKU:AUD-127d3c
Upgrade your audio amplifiers with high-fidelity Triad J Series Transformer for exceptional sound performance.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
High Fidelity 1740 Ohm Primary DC Resistance Audio Transformer
$89.99
Quantity: 1
Claim Your Seller Account
High Fidelity 1740 Ohm Primary DC Resistance Audio Transformer
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance your audio amplifiers with the Triad J Series Audio Transformer. Designed to exceed broadcast standards, this transformer offers exceptional performance at an affordable price. With a primary DC resistance of 1740 Ohm and a range of secondary impedances, it ensures high-fidelity sound reproduction. The unit features low-level hum, wide frequency response, and is shielded for electromagnetic interference protection, making it ideal for plate to line applications.
Product Specifications
Applications Applications
Plate to Line
Direct Current Dc Resistance Dc Resistance Primary
1740 Ohm
Direct Current Dc Resistance Dc Resistance Secondary
81.2 Ohm
Electrical Specifications At 25 Degree Celsius C Temperature Max
100 mW
Electrical Specifications At 25 Degree Celsius C Temperature Ove
5:1
Electrical Specifications At 25 Degree Celsius C Temperature Pri
15000 Ohm
Electrical Specifications At 25 Degree Celsius C Temperature Sec
50 Ohm | 250 Ohm | 600 Ohm
Features Features
Low level high fidelity.Single-hole mounting, allowing rotation for maximum hum reduction. Alloy shielding gives 40 to 60 dB hum reduction. Wide frequency ranges. Flexible leads for ease of mounting. Input units electrostatically and magnetically shielded .Lightweight. Smooth, baked enamel cases, 1-3/8" diameter, 1-3/4" above chassis . Legible circuit diagrams permanently affixed to every case.
Matching Impedance Direct Current Dc For Primary Matching Impeda
4 mA
Note Note
Static Shield
Specifications Case Dimension D
1-3/8 in
Specifications Case Dimension H
1-3/4 in
Specifications Case Type
J
Specifications Connections
Leads
Specifications Frequency Response At 3 Db
40 to 15000
Specifications Hum Reduction
40 to 60 dB
Specifications Maximum Unit Weight
0.35 lb
Specifications Mounting Hole Diameter
3/8 in
Specifications Rms Test Voltage
500
