High-Flow Engine Driven Trash Pump - 1.5" & 2"

High-Flow Engine Driven Trash Pump - 1.5" & 2"

PRO-bda206

High-Flow Trash Pump with Solid Handling, Self-Priming, and Multi-Engine Options for Efficient Water Management

$1,399.99
$1,399.99
Sale

Initiate Order

High-Flow Engine Driven Trash Pump - 1.5" & 2"

High-Flow Engine Driven Trash Pump - 1.5" & 2"

$1,399.99

Quantity: 1

Claim Your Seller Account

High-Flow Engine Driven Trash Pump - 1.5" & 2"

High-Flow Engine Driven Trash Pump - 1.5" & 2"

$1,399.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The High-Flow Engine Driven Trash Pump offers exceptional flow efficiency and solids handling for demanding applications. Featuring robust sand-cast components with removable/replaceable Cast Iron volutes, impellers, and wear plates, it ensures durability and easy maintenance. This reliable pump self-primes up to 20 ft and accommodates various non-flammable liquids. Engine options include Honda, Briggs & Stratton Gasoline, or Yanmar diesel for versatile performance. With a range of NPT port sizes, a Viton®/Silicon Carbide Mechanical Seal, and heavy-duty construction, it's ideal for institutional and industrial use.

Product Specifications

Specifications Curve
B
Specifications Customs Code
HTS Code 8413702015
Specifications Driver
Honda GX160
Specifications Features
Two NPT Pipe NipplesViton®/Silicon Carbide Mechanical SealBuna-N O-Ring Casing SealSelf-primes to 20 ft with Built In Buna Check ValveStainless Steel Shaft SleeveSteel Suction Strainer IncludedCast Iron Replaceable Volute/Wear plate & ImpellerMaximum Temperature 180°FMaximum Working Pressure 60 PSI1.5", 2" & 3" Models Include Steel Roll Frame4" Models Include Wheel Kit and Base RailsVanguard and Honda Engines are Overhead Valve (OHV) Designs with Low Oil Alert and Briggs &Stratton 1350 Series Engine with Oil Alert and High Oil Fill.
Specifications Fuel Tank Capacity
3.8 qt
Specifications Height
19 in | 472.44 mm
Specifications Length
24 in | 609.60 mm
Specifications Manufacturer
American Machine and Tool Company
Specifications Motor Frame
Yes
Specifications Power
5 1/2 hp
Specifications Run Time
100 min
Specifications Seal Material
Viton®/SIC
Specifications Sku
AT393295SP
Specifications Solids Handling
1 in
Specifications Weight
115 | 52.16 | 110 lbs
Specifications Width
19 in | 487.68 mm
