High Force 1-1/4 NPT Zinc Aluminum Alloy Super Air Nozzle
High Force 1-1/4 NPT Zinc Aluminum Alloy Super Air Nozzle
SKU:HIG-dd7727
High Force Super Air Nozzle with 9.4 lbs blowing force, 80 psig pressure, and 188 SCFM air consumption. Enhance productivity and safety.
Regular price
$99.99
Regular price
Sale price
$99.99
Unit price
per
Initiate Order
High Force 1-1/4 NPT Zinc Aluminum Alloy Super Air Nozzle
$99.99
Quantity: 1
Claim Your Seller Account
High Force 1-1/4 NPT Zinc Aluminum Alloy Super Air Nozzle
$99.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The High Force 1-1/4 NPT Zinc Aluminum Alloy Super Air Nozzle is designed to deliver exceptional blowing force, producing 9.4 lbs (4.25 kg) of force – nearly 12 times that of standard nozzles. Crafted from durable Zinc Aluminum alloy, it operates at 80 psig (5.5 bar) pressure, with an air consumption of 188 SCFM (5324 SLPM). This versatile nozzle is ideal for various applications like air assist, chip removal, part cooling, and more. With advantages like reduced noise levels, improved production efficiency, safety enhancements, and meeting OSHA requirements, it is a reliable choice for industrial needs.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Advantages
10 dBA Average Noise Reduction | Compact | Conserve Compressed Air | Improved Blowoff Performance | Improved Production | Improved Safety | Meets OSHA Noise Level Requirements | Meets OSHA Pressure Requirements | Reduced Compressed Air Cost
Specifications Air Consumption
188 SCFM | 5324 SLPM
Specifications Applications
Air Assist | Chip Removal | Fiber Conveying | Liquid Blowoff | Material Conveying | Part Cleaning | Part Cooling | Part Drying | Part Ejection
Specifications Force
9.4 lb | 4252 g
Specifications Inlet
1-1/4 FNPT
Specifications Material
Zinc Aluminum alloy
Specifications Note
Force measured at 12" (305 mm) from target
Specifications Pressure
80 psig | 5.5 bar
Specifications Sound Level
102 dBA
