High Force Air Nozzle - 3/4 NPT Super Air Nozzle
High Force Air Nozzle - 3/4 NPT Super Air Nozzle
SKU:HIG-20d135
High Force Air Nozzle - 3/4 NPT Super Air Nozzle - Extreme force, optimal durability, and OSHA-compliant.
Regular price
$149.99
Regular price
Sale price
$149.99
Unit price
per
Initiate Order
High Force Air Nozzle - 3/4 NPT Super Air Nozzle
$149.99
Quantity: 1
Claim Your Seller Account
High Force Air Nozzle - 3/4 NPT Super Air Nozzle
$149.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The High Force Air Nozzle - 3/4 NPT Super Air Nozzle from EXAIR delivers exceptional blowing force of 4.5 lbs, ideal for applications requiring extreme force. Crafted from Zinc Aluminum alloy, this nozzle ensures durability. With a noise level of 96 dBA and 10 dBA average noise reduction, it offers improved safety and meets OSHA noise level requirements. Conserve compressed air with 91 SCFM air consumption while enhancing production efficiency. This compact powerhouse is versatile, suitable for various applications like Chip Removal, Part Cleaning, and Material Conveying, making it an essential tool for industrial settings.
Product Specifications
Specifications Advantages
10 dBA Average Noise Reduction | Compact | Conserve Compressed Air | Improved Blowoff Performance | Improved Production | Improved Safety | Meets OSHA Noise Level Requirements | Meets OSHA Pressure Requirements | Reduced Compressed Air Cost
Specifications Air Consumption
91 SCFM | 2577 SLPM
Specifications Applications
Air Assist | Chip Removal | Fiber Conveying | Liquid Blowoff | Material Conveying | Part Cleaning | Part Cooling | Part Drying | Part Ejection
Specifications Force
4.5 lb | 2041 g
Specifications Inlet
3/4 FNPT
Specifications Material
Zinc Aluminum alloy
Specifications Note
Force measured at 12" (305 mm) from target
Specifications Pressure
80 psig | 5.5 bar
Specifications Sound Level
96 dBA
