High-Force Stainless Steel Air Nozzle - 1112SS
High-Force Stainless Steel Air Nozzle - 1112SS
SKU:HIG-dc2119
High-Force Stainless Steel Air Nozzle - 1112SS for extreme blowing force applications, meets OSHA standards.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
High-Force Stainless Steel Air Nozzle - 1112SS
$59.99
Quantity: 1
Claim Your Seller Account
High-Force Stainless Steel Air Nozzle - 1112SS
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The High-Force Stainless Steel Air Nozzle - 1112SS is designed for applications requiring extreme blowing force. With a 3/4 FNPT inlet and constructed from durable 316 stainless steel, this powerful nozzle delivers 4.5 lbs (2041 g) of force at 80 psig (5.5 bar). It excels in various tasks including air assist, chip removal, part cleaning, and more, enhancing production efficiency and safety. Featuring a compact design, 10 dBA noise reduction, and reduced air consumption, this nozzle meets OSHA noise and pressure requirements, offering a reliable solution for industrial needs.
Product Specifications
Specifications Advantages
10 dBA Average Noise Reduction | Compact | Conserve Compressed Air | Improved Blowoff Performance | Improved Production | Improved Safety | Meets OSHA Noise Level Requirements | Meets OSHA Pressure Requirements | Reduced Compressed Air Cost
Specifications Air Consumption
91 SCFM | 2577 SLPM
Specifications Applications
Air Assist | Chip Removal | Fiber Conveying | Liquid Blowoff | Material Conveying | Part Cleaning | Part Cooling | Part Drying | Part Ejection
Specifications Force
4.5 lb | 2041 g
Specifications Inlet
3/4 FNPT
Specifications Material
316 Stainless Steel
Specifications Note
Force measured at 12" (305 mm) from target
Specifications Pressure
80 psig | 5.5 bar
Specifications Sound Level
96 dBA
