High-Impact PVC Type II Light Gray Sheet
High-Impact PVC Type II Light Gray Sheet
SKU:SHA-1abd0d
Durable high-impact PVC sheet with superior resistance to corrosion and impact, ideal for thermal forming applications. Meets ASTM D1784, CLASS 16444-D standards.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
High-Impact PVC Type II Light Gray Sheet
$39.99
Quantity: 1
Claim Your Seller Account
High-Impact PVC Type II Light Gray Sheet
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Our High-Impact PVC Type II Light Gray Sheet is a versatile thermoplastic material with exceptional chemical resistance, mechanical strength, and dimensional stability. Ideal for thermal forming applications, this grade meets ASTM D1784, CLASS 16444-D standards, ensuring high impact resistance and corrosion resistance. With superior physical properties like a Vicat Softening Point of 181°F and a Flammability Rating of V0, this PVC sheet is suitable for a range of institutional and industrial uses. Customize your order with optional sheet sizes.
Product Specifications
Specifications Density Astm D792
1.35 gm/cc
Specifications Dielectric Strength Astm D149
645 V/mil
Specifications Flame Spread E84
15
Specifications Flammability Rating Ul 94
V0
Specifications Flexural Modulus
400000 psi
Specifications Flexural Strength
10000 psi
Specifications Hardness Durometer Shore D
85
Specifications Hardness Rockwell Astm D785
R106
Specifications Heat Deflection Temperature 264 Psi
179 ºF
Specifications Izod Impact Strength Astm D256
18 ft·lb/in
Specifications Optional Sheet Size
12 x 24 | 12 x 36 | 24 x 120 | 24 x 24 | 24 x 96 | 36 x 48 | 48 x 48 | 48 x 72 | 60 x 120
Specifications Sheet Size
12 x 12 in
Specifications Tensile Modulus Astm D638
396000 psi
Specifications Tensile Strength Astm D638
7400 psi
Specifications Thickness
0.625 in
Specifications Vicat Softening Point Astm D1525
181 ºF
Specifications Water Absorption 24 Hrs 73f Astm D570
0.16 %
Specifications Weight
4.69 lb/ft²
