High-Performance ABS/CNT Composite (1.05 Spec. Gravity, 30 Tensile Elongation)
High-Performance ABS/CNT Composite (1.05 Spec. Gravity, 30 Tensile Elongation)
SKU:ACR-4a4b8a
Unmatched strength and durability with High-Performance ABS/CNT Composite. Ideal for high-rigidity applications. ASTM-tested for quality.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
High-Performance ABS/CNT Composite (1.05 Spec. Gravity, 30 Tensile Elongation)
$49.99
Quantity: 1
Claim Your Seller Account
High-Performance ABS/CNT Composite (1.05 Spec. Gravity, 30 Tensile Elongation)
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience unmatched strength and thermal stability with our High-Performance ABS/CNT Composite. With a specific gravity of 1.05 and 30% tensile elongation, this composite is ideal for applications requiring high rigidity. Tested to ASTM standards, our composite offers enhanced flexural strength, conductivity, and heat deflection temperature. Increase efficiency with uniform conductivity for boxes, electronic parts trays, and coatings. Join major global manufacturers in using Kumho's CNT for automotive, electronic, and shielding applications.
Product Specifications
Additional Information
The products coated in conductive solution have increased adhesion, mechanical strength and abrasion resistance.MAB150 is excellent in gloss and surface quality and MAB150M is outstanding in recognition rate of laser marking.Electro-conductivity is revealed by the addition of CNT to ABSEAB120 can be processed by the non-painting and increase painting efficiency with uniform conductivityCNT is known as having excellent electrical conductivity, thermal conductivity, strength, and thermal stability. Demand for Li-ion Battery as positive electrode conductive additives has been increasing and CNT is also being used in applications such as tire treads and antistatic resins.Kumho's CNT have a highly oriented bundle structure and have been used by major battery manufacturers and tire manufacturers globally. Multiple grades of CNT are available depending on required property and each application, and we also have various types of rubber and resin compound and masterbatches.Kumho Petrochemical with one of the world's largest synthetic rubber manufacturing capacities was established in 1970 and developing their business in several fields including synthetic resins, specialty chemicals, nanocarbons, energy, and building materials.Major application with Kumho's CNTLi-ion Battery as positive electrode conductive additives for automotiveTire treadsElectronic Parts TraysConductive coatingElectro-Magnetic Interference (EMI) Shielding CompositeConductive resin/rubber
Applications Applications
Boxes | Electrostatic Painting Parts
Applications Surface Resistance
108~1010 Ω/sq.
Technical Specs Brands
Heidon
Properties Flexural Modulus 10 Millimeter Mm Per Minute
22,100 kgf/cm²
Properties Flexural Strength 10 Millimeter Mm Per Minute
650 kgf/cm²
Properties Heat Deflection Temperature 186 Kilogram Kgsq
95 ºC
Properties Izod Impact Notched 32 Millimeter Mm
10 kgf·cm/cm
Properties Melt Flow Index 200 Degree Celsius C Temperat
9 g/10min
Properties Rockwell Hardness R Scale
105
Properties Specific Gravity
1.05
Properties Tensile Elongation At Break 50 Millimeter Mm
30 %
Properties Tensile Strength 50 Millimeter Mm Per Minute
470 kgf/cm²
Properties Test Method For Flexural Modulus 10 Millimete
American Society for Testing and Materials (ASTM) D256
Properties Test Method For Flexural Strength 10 Millimet
American Society for Testing and Materials (ASTM) D790
Properties Test Method For Heat Deflection Temperature 1
American Society for Testing and Materials (ASTM) D648
Properties Test Method For Izod Impact Notched 32 Millim
American Society for Testing and Materials (ASTM) D256
Properties Test Method For Melt Flow Index 200 Degree Ce
American Society for Testing and Materials (ASTM) D1238
Properties Test Method For Rockwell Hardness R Scale
American Society for Testing and Materials (ASTM) D785
Properties Test Method For Specific Gravity
American Society for Testing and Materials (ASTM) D792
Properties Test Method For Surface Resistivity At 23 Deg
American Society for Testing and Materials (ASTM) D257
Properties Test Method For Tensile Elongation At Break 5
American Society for Testing and Materials (ASTM) D638
Properties Test Method For Tensile Strength 50 Millimete
American Society for Testing and Materials (ASTM) D638
