High Performance Alloy 6BH, 0.250 in Size Cobalt Plate
High Performance Alloy 6BH, 0.250 in Size Cobalt Plate
SKU:COB-8d05c9
Superior hardness and wear resistance with FDA approval for food contact. Ideal for industrial applications.
Regular price
$199.99
Regular price
Sale price
$199.99
Unit price
per
Initiate Order
High Performance Alloy 6BH, 0.250 in Size Cobalt Plate
$199.99
Quantity: 1
Claim Your Seller Account
High Performance Alloy 6BH, 0.250 in Size Cobalt Plate
$199.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The High Performance Alloy 6BH in 0.250 inch size offers exceptional wear life and hardness (C40 min), making it ideal for various applications such as steam turbine erosion shields, food processing equipment, and hot extrusion dies. With a composition of Co 59.0, Cr 30.0, W 3.5, Ni 2.5, Mn 1.4, C 1.0, this plate type alloy provides superior galling and wear resistance, meeting the rigorous demands of institutional and industrial use. Cobalt 6BH is FDA-approved for food contact and well-suited for valve parts, pump plungers, and other high-wear environments.
Product Specifications
Additional Information Additional Information
Other non-critical uses include tire cloth and rubber cutting, carpet cutting, trimming knives for ceramics, leather knives, and surgical blades.Cobalt 6BH is the same composition of Cobalt 6B, except the material is hot rolled and then age hardened. The direct age-hardening after hot rolling provides the maximum hardness and wear resistance. The advantages this creates are increased wear life, retained edge characteristics, and increased hardness. These properties are in addition to the galling and seizing resistance of the regular Cobalt 6B.Cobalt 6BH is known in the industry as a metal that retains its cutting edge. The economic advantages are in its long wear time, less down time, and fewer replacements. This material surpasses 6K with better ductility, with the same good hardness.
Applications 0
Steam turbine erosion shields, Chain saw guide bars, High temperature bearings, Furnace fan blades, Valve stems, Food processing equipment, Needle valves, Centrifuge liners, Hot extrusion dies, Forming dies, Nozzles, Extruder screws & many other Misc. wear surfaces.Applications for alloy 6BH also include tile making machines, rock crushing rollers and cement and steel mill equipment. Alloy 6BH is well suited for valve parts, pump plungersWrought alloy 6BH offers the fatigue resistance and toughness of a hot worked microstructure, with the heat corrosion and wear resistance of cobalt based alloy. High Performance Alloys, Inc. inventories sheet, and plate. Bar is can be produced 1/2" through 2-1/2" diameter. Bar can be supplied in random lengths or cut to order. Sheet and plate are offered as whole plates, can be abrasive cut, or processed further using water jet services.
General Resistance General Resistance
Wear | Galling
General Resistance Unified Numbering System Uns
R30016
Mechanical Elongation
4 %
Mechanical Hardness
C40 min
Mechanical Mechanical Type
Aged
Nominal Chemistry Carbon C
1
Nominal Chemistry Chromium Cr
30
Nominal Chemistry Cobalt Co
59
Nominal Chemistry Iron Fe
Balanced
Nominal Chemistry Manganese Mn
1.4
Nominal Chemistry Nickel Ni
2.5
Nominal Chemistry Tungsten W
3.5
Physical Density
0.330 lb/in³
Specifications Alloy
6BH
Specifications Size
0.250 in
Specifications Type
Plate
