High-Performance Wire Inserted Graphite Gasket
High-Performance Wire Inserted Graphite Gasket
SKU:FLE-21e8ca
High-performance graphite gasket for superior sealing. Resistant to extreme temperatures and various chemicals. Ideal for critical applications.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
High-Performance Wire Inserted Graphite Gasket
$29.99
Quantity: 1
Claim Your Seller Account
High-Performance Wire Inserted Graphite Gasket
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wire Inserted Flexible Graphite Gasket is a versatile solution designed to excel in demanding applications. With a temperature range of -380 to 900 °F, available in multiple thicknesses, and a sheet size of 39.4 x 39.4 inches, this gasket self-forms during assembly torque down for a perfect fit. Resistant to a wide range of acids, solvents, and oils, impermeable to gases and fluids, and corrosion-resistant, it is ideal for sealing high-temperature valves, shafts, and flanges. Notable exceptions include strong oxidizing compounds. This gasket combines reliability with high thermal conductivity for superior performance in critical environments.
Product Specifications
Specifications Applications
Ultimate material for critical applications. The gasket self-forms during torque down of assembly thus ensuring a perfect fit to flange faces:Resistant to organic, inorganic acids, solvents, hot wax and oils | Impermeable to gases and fluids, corrosion resistant | Excellent for sealing high temperature valves, shafts, and flanges, high thermal conductivityExceptions are Strong oxidizing compounds such as:Concentrated nitric acids, high concentrated sulphuric acids, chromium (VI) and permanganate solutions,
Specifications Available Thickness
1/16 in | 1/8 in | 1/32 in | 1/64 in
Specifications Sheet Size
39.4 x 39.4 in
Specifications Temperature Range
-380 to 900 ºF | -229 to 482 ºC
