High Pressure Anti-Vibration Collet Gland Assembly - 150,000 psi MAWP
High Pressure Anti-Vibration Collet Gland Assembly - 150,000 psi MAWP
SKU:BEA-c99ecd
High Pressure Anti-Vibration Collet Gland Assembly for extreme conditions, 1/4" to 3/8" sizes, up to 150,000 psi
Regular price
$189.99
Regular price
Sale price
$189.99
Unit price
per
Initiate Order
High Pressure Anti-Vibration Collet Gland Assembly - 150,000 psi MAWP
$189.99
Quantity: 1
Claim Your Seller Account
High Pressure Anti-Vibration Collet Gland Assembly - 150,000 psi MAWP
$189.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The High Pressure Anti-Vibration Collet Gland Assembly is designed to withstand pressures up to 150,000 psi, making it ideal for extreme vibration and shock conditions in tubing systems. This assembly features Autoclave coned and threaded connections, providing a secure and reliable grip on tubing. The collet gland assembly offers a simple yet effective design, utilizing tapered and slotted collets that wedge securely into place as the nut tightens. With dimensions to 1/4 inch, 5/16 inch, and 3/8 inch, this assembly ensures a tight, vibration-resistant connection for critical applications.
Product Specifications
Manufacturing Notes 0
For 1: It is recommended that holes to suit bearing mounting studs should be reamed to tolerance F6 for a sliding fit.For 2: Nuts and washers are supplied with both concentric and eccentric RSJ/RLJ type bearings.For Dimension N & R: 'N' is the eccentric offset due to the double eccentric design (2 x N = total stroke). R dimension is both the eccentric offset of the adjusting nut and total stroke at the bearing centerline.For Dimension B1: Controlled height (CHK) bearings are selected in ±0.010mm bands in respect of the B1 dimension. They are supplied in sets of up to 50 parts as standard, with larger sets on request.For 5: For adjusting tool part numbers see table. For adjustment procedure and fixing nut tightening torques see 58.For 6: Fasteners for the through fixing type bearings are black on the concentric version and bright zinc plated on the eccentric version for identification purposes, except stainless steel type.For 7: Stainless steel bearings are only available nitrile sealed
