High-Pressure Ball Check Valves - NPT Connection, Brass/Stainless Steel Construction

Name: High-Pressure Ball Check Valves - NPT Connection, Brass/Stainless Steel Construction
Brand: O'Keefe Controls Co.
SKU: CHE-e7b605
Price: 49.99 USD
Availability: OutOfStock

SKU:CHE-e7b605

High-Pressure Ball Check Valves for reliable one-way flow. Durable brass/stainless steel construction for industrial use.

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Our high-pressure ball type check valves with NPT connections are designed for superior performance in both liquids and gases. Available in 303 SS material, with a 304 SS ball, these valves ensure free flow in one direction, preventing reverse flow. Featuring a maximum operating pressure gauge of 200 psig and a maximum temperature of 300°F, these valves are durable and reliable. With all-metal construction and a choice of cracking pressure, they offer long life operation and high-pressure capability, making them ideal for industrial applications.

Product Specifications

Dimensions Total Length

1.25 in

Dimensions Width Across Flats Hex

3/4 in

Features Features

All metal construction Long life operation Choice of cracking pressure High pressure capability

Flow Data Air Flow At 100 Psig

781 ftÂ³/h

Flow Data Water Flow At 100 Psig

1.9 gpm

Specifications Ball Material

304 SS

Specifications Connection A

1/4" NPT Female

Specifications Connection B

1/4" NPT Male

Specifications Cracking Pressure

15 psig

Specifications Cv

0.190

Specifications Material

303 SS

Specifications Maximum Operating Pressure Gauge

200 psig

Specifications Maximum Temperature

300 ÂºF

Specifications Seat Leakage

20 SSCM (max.) air flow at 25 psi differential
