High Pressure Ball Type Excess Flow Valve - 60000 psi
High Pressure Ball Type Excess Flow Valve - 60000 psi
SKU:INT-be4b31
Protect pressure gauges & instrumentation from surges with our 60000 psi High Pressure Ball Type Excess Flow Valve.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
High Pressure Ball Type Excess Flow Valve - 60000 psi
$129.99
Quantity: 1
Claim Your Seller Account
High Pressure Ball Type Excess Flow Valve - 60000 psi
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The High Pressure Ball Type Excess Flow Valve is engineered to safeguard pressure gauges and instrumentation from sudden flow surges or venting in case of line failure. Crafted from durable 316 Stainless Steel, this valve features a non-spring loaded ball design for reliable performance. With a Pressure Rating of 60000 psi and precise Orifice of 0.094 inches, it ensures optimal safety and control in high-pressure systems. The vertical installation requirement with automatic resetting mechanism enhances operational efficiency and maintenance. Frequent inspections are recommended to monitor O-ring integrity for prolonged service life.
Product Specifications
Drilling Positions Dimension B
48.3 mm
Drilling Positions Dimension C
52.1 mm
Drilling Positions Dimension D
3.9 mm
Drilling Positions Dimension E
89.5 mm
Drilling Positions Dimension F
45.5 mm
Drilling Positions Dimension G
33 mm
Drilling Positions Dimension H
38 mm
Manufacturing Notes 0
For 1 : Short or long stud lengths are available for each size of bearing 34-35. Choose according to the required mounting plate thickness.For 2 : Exact theoretical values have been given for `B`, `C` and `D`. Positional accuracy of dimension `B` will determine the axis of the ring. Positional accuracy for dimensions `C` and `D` are not normally critical. Holes for bearing studs should be reamed to tolerance F6 for a sliding fit.For 3 : The eccentric blind hole fixing bearing cannot be used with the RIS 182 ring slide as it clashes with the ring.
