High-Pressure Brass 2-Way Ball Valve, BSP Thread
High-Pressure Brass 2-Way Ball Valve, BSP Thread
SKU:ACC-947e4b
Premium high-pressure brass ball valve for precise industrial flow control.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
High-Pressure Brass 2-Way Ball Valve, BSP Thread
$59.99
Quantity: 1
Claim Your Seller Account
High-Pressure Brass 2-Way Ball Valve, BSP Thread
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience superior performance and durability with our High-Pressure Brass 2-Way Ball Valve designed for industrial applications. Constructed with brass body and spindle, featuring a forged housing and aluminum handle, this valve ensures reliable flow control. Compliant with International Organization for Standardization (ISO) standards, it offers a secure connection and precise operation in temperatures ranging from 14°F to 176°F.
Product Specifications
Dimensions Connection Size
G 1 (BSP)
Specifications Bun
EA
Specifications Connection Type
(BSP) Female Thread
Specifications Division
ACCESSORIES
Specifications Flow Direction
2-Way
Specifications Handle Codes
Offset Aluminum
Specifications Housing Type
Forged Housing
Specifications Industry Standardscertifications
International Organization for Standardization (ISO)
Specifications Material Body
Brass
Specifications Material Handle
Aluminum
Specifications Material Housing
Brass
Specifications Material Spindle And Ball
Brass
Specifications Model Code Description
KHN3K-G1-L-2233-12X
Specifications Note For Maximum Pressure
Dependent upon valve and seal materials selected.
Specifications Operating Temperature Max
176 ºF
Specifications Operating Temperature Min
14 ºF
Specifications Product
BALL VALVES
Specifications Product Group Family
BALL VALVES-LOW PRESSURE (<3000 PSI)
Specifications Type
Ball Valve
Specifications Valve Operator
Handle
