High Pressure Connection Plug 60,000 psi MAWP
High Pressure Connection Plug 60,000 psi MAWP
SKU:LUB-81a6ad
Engineered for 60,000 psi MAWP, perfect for 1-inch tubing & 30SC/43Y valves/fittings, unmatched strength & reliability.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
High Pressure Connection Plug 60,000 psi MAWP
$49.99
Quantity: 1
Claim Your Seller Account
High Pressure Connection Plug 60,000 psi MAWP
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The High Pressure Connection Plug is engineered by Autoclave for unparalleled performance at pressures up to 60,000 psi (4137 bar). Designed for seamless integration with 1-inch tubing, it ensures exceptional reliability in conjunction with 30SC and 43Y valves and fittings. Crafted with precision to meet the most demanding industrial requirements, this plug guarantees secure connections under extreme pressures. Ideal for applications necessitating robust high-pressure fittings, this component ensures efficient fluid handling and superior durability.
Product Specifications
Manufacturing Notes 0
For 1: 2 machine screws with cross-recessed pan heads to DIN7985A are supplied for fixing the flanged type lubricator (see J1 in table). Additionally, 2 self tapping screws for plastic with PT thread form and cross-recessed pan heads are supplied for the compact type lubricator (see J in table).For 2: Lubrication interval depends on length of stroke, duty and environmental factors. Replenish lubricant as necessary using a 68 viscosity EP mineral oil.For 3: Size 25,44 & 76 lubricators are available with increased clearance "H1" to accommodate the "V float" of the floating bearings
Specifications Dimension A1 Type C
7 mm
Specifications Dimension A Type F
17 mm
Specifications Dimension B
10 mm
Specifications Dimension C
13 mm
Specifications Dimension D
5.2 mm
Specifications Dimension E
2 mm
Specifications Dimension F
3 mm
Specifications Dimension G1 01
12 mm
Specifications Dimension G 01
6.5 mm
Specifications Dimension H
3.1 mm
Specifications Dimension I
3 mm
Specifications Dimension J1 Hole
2.7 mm
Specifications Dimension J1 Screw Size
M2.5 x 6
Specifications Dimension J
2.5 mm
Specifications Dimension J Length
5 mm
Specifications Dimension K
2.5 mm
Specifications Dimension L
3 mm
Specifications Dimension M
5.46 mm
Specifications Dimension N
9 mm
Specifications Dimension O
2.2 mm
Specifications For Use With Ring Slides
R12
Specifications For Use With Track System
TNMS 12
Specifications Weight
2 g
