High Purity Constantan Sputtering Targets
High Purity Constantan Sputtering Targets
SKU:CON-2878ff
Premium Constantan sputtering targets for high-performance applications. Ensure precision and reliability in sputtering processes.
Regular price
$189.99
Regular price
Sale price
$189.99
Unit price
per
Initiate Order
High Purity Constantan Sputtering Targets
$189.99
Quantity: 1
Claim Your Seller Account
High Purity Constantan Sputtering Targets
$189.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Constantan (Cu55/Ni45) Resistance Sputtering Targets are precision-crafted to meet the demanding requirements of sputtering processes. With a thickness of 3mm and diameters ranging from 50.8mm to 75mm, these targets ensure optimal performance. Featuring exceptional electrical resistivity of 52 µΩ·cm, thermal conductivity of 19.50 W m-1K-1, and a maximum use temperature of 500ºC, they guarantee reliability in extreme conditions. The Constantan alloy's superior mechanical properties, including a tensile strength of 400.00 to 590.00 MPa and a modulus of elasticity of 162.0 GPa, make these targets ideal for high-precision applications.
Product Specifications
Electrical Properties Electrical Resistivity
52 µΩ·cm
Electrical Properties Temperature Coefficient Tolerance
0.00002 k-1
Material Material
Constantan Resistance AlloyAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities).Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
Mechanical Properties Elongation At Break
< 45.0 %
Mechanical Properties Hardness Brinell
100 to 300
Mechanical Properties Izod Impact Strength
107.0 J m-1
Mechanical Properties Modulus Of Elasticity
162.0 GPa
Mechanical Properties Tensile Strength
400.00 to 590.00 MPa
Physical Properties Density
8.900 g·cm-3
Specifications Diameter
50.8 to 75 mm
Specifications Thickness
3 mm
Thermal Properties Coefficient Of Thermal Expansion At 20 To 100
14.900 x10-6 K-1
Thermal Properties Maximum Use Temperature In Air
500 ºC
Thermal Properties Melting Point
1225.00 to 1300.00 ºC
Thermal Properties Thermal Conductivity At 23 Degree Celsius C T
19.50 W m-1K-1
Tolerances Disc Diameter Tolerance
0.5 mm
Tolerances Thickness Tolerance
0.5 mm
