High-Purity Sapphire Al2O3 Powder
High-Purity Sapphire Al2O3 Powder
SKU:SAP-ffca7c
High-purity Sapphire Al2O3 Powder with exceptional properties for varied applications.
Regular price
$79.99
Regular price
Sale price
$79.99
Unit price
per
Initiate Order
High-Purity Sapphire Al2O3 Powder
$79.99
Quantity: 1
Claim Your Seller Account
High-Purity Sapphire Al2O3 Powder
$79.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Our Sapphire (Al2O3) Powder is a high-purity material meeting stringent institutional standards. With a maximum particle size of 60 µm, this powder offers exceptional chemical resistance to acids, alkalis, and halogens. Its mechanical properties include high hardness and tensile strength, making it ideal for various applications. The ceramic-based powder boasts excellent thermal conductivity, refractive index, and thermal expansion qualities, making it a top choice for demanding industries.
Product Specifications
Chemical Resistance Alkalis
Good
Chemical Resistance Concentrated Acids
Good
Chemical Resistance Dilute Acids
Good
Chemical Resistance Halogens
Good
Chemical Resistance Metals
Good
Electrical Properties Dielectric Constant
7.5 to 11.5
Electrical Properties Dielectric Strength
15.0 to 50.0 kV mm-1
Electrical Properties Volume Resistivity At 25 Degree Celsius C
> 1014 µΩ·cm
Material Material
SapphireThis is synthetically produced Sapphire. Single crystal Sapphire has a high thermal conductivity, volume resistivity, hardness and wear resistance, as well as a high upper use temperature. The energy band gap is large (10eV). Sapphire is a transparent material having useful transmission of wavelengths in the range 0.2 to 5.5 microns. It is much stronger than glass and can be used as viewing windows in high pressure and vacuum applications.
Mechanical Properties Hardness Knoop
2000 Kgf mm-2
Mechanical Properties Hardness Vickers
1600 to 1800 Kgf mm-2
Mechanical Properties Tensile Modulus
350.00 to 390.00 GPa
Mechanical Properties Tensile Strength
250.00 to 400.00 MPa
Physical Properties Compressive Strength
2100 MPa
Physical Properties Density
3.985 g·cm-3
Physical Properties Refractive Index
1.710 to 1.790
Physical Properties Useful Optical Transmission Range
200 to 5500 nm
Physical Properties Water Absorption Saturation
0 %
Pultrusion Apparent Porosity
0.00 %
Specifications Form
Powder
Specifications Maximum Particle Size
60 µm
Specifications Weight
50 to 200 g
Thermal Properties Coefficient Of Thermal Expansion At 20 To 100
5.800 x10-6 K-1
Thermal Properties Melting Point
2050.00 ºC
Thermal Properties Specific Heat At 25 Degree Celsius C Temperat
750.0 J K-1 kg-1
Thermal Properties Thermal Conductivity At 20 Degree Celsius C T
35.00 to 40.00 W m-1K-1
Thermal Properties Upper Continuous Use Temperature
1800 to 1950 ºC
Type Type
CeramicCeramics are non-metallic, non-organic materials. They exhibit excellent resistance to high temperatures. Although they have comparatively low densities, they are extremely hard but tend to be brittle. They show good resistance to both abrasives and chemicals.
