High-Purity Titanium Alloy Foil - Ti78.8/Mo15/Nb3/Al3/Si0.2
High-Purity Titanium Alloy Foil - Ti78.8/Mo15/Nb3/Al3/Si0.2
SKU:TIT-03db69
Durable & conductive Titanium Alloy Foil - Ti78.8/Mo15/Nb3/Al3/Si0.2. Ideal for industrial applications, meeting strict standards.
Regular price
$99.99
Regular price
Sale price
$99.99
Unit price
per
Initiate Order
High-Purity Titanium Alloy Foil - Ti78.8/Mo15/Nb3/Al3/Si0.2
$99.99
Quantity: 1
Claim Your Seller Account
High-Purity Titanium Alloy Foil - Ti78.8/Mo15/Nb3/Al3/Si0.2
$99.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience the exceptional durability and conductive properties of our Titanium/Molybdenum/Niobium/Aluminium/Silicon (Ti78.8/Mo15/Nb 3/Al 3/Si 0.2) Foil. With a thickness of 0.5 mm and a tensile strength of 930.00 MPa, this foil is perfect for a wide range of industrial applications. Its high melting point of 815.00 to 900.00 ºC ensures stability under extreme conditions. Compliant with stringent industry standards, this foil is an ideal choice for government and institutional procurement needs.
Product Specifications
Electrical Properties Electrical Resistivity
135 µΩ·cm
Material Material
Titanium AlloysAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities).Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
Mechanical Properties Elongation At Break
< 14.0 %
Mechanical Properties Modulus Of Elasticity
96.0 to 103.0 GPa
Mechanical Properties Tensile Strength
930.00 MPa
Physical Properties Density
4.930 g·cm-3
Specifications Form
Foil
Specifications Light Tight Size
80 x 101 mm
Specifications Temper
As Rolled
Specifications Thickness
0.5 mm
Thermal Properties Coefficient Of Thermal Expansion At 20 To 100
7.070 x10-6 K-1
Thermal Properties Melting Point
815.00 to 900.00 ºC
Thermal Properties Specific Heat At 23 Degree Celsius C Temperat
490.0 J K-1 kg-1
Thermal Properties Thermal Conductivity At 23 Degree Celsius C T
7.60 W m-1K-1
Tolerances Tolerance For 001 Millimeter Mm Thickness
25 %
Tolerances Tolerance For 005 Millimeter Mm Thickness
10 %
Tolerances Tolerance For 100 Millimeter Mm Coil Length
+2 % | -1 %
Tolerances Tolerance For 100 Millimeter Mm Disc Diameter
+2 % | -1 %
Tolerances Tolerance For 100 Millimeter Mm Length 1 Light Tight
+2 % | -1 %
Tolerances Tolerance For 100 Millimeter Mm Length 2 Light Tight
+2 % | -1 %
