High-Quality 3-Pin Blue Wire Mount Socket Connector
High-Quality 3-Pin Blue Wire Mount Socket Connector
SKU:PRO-1f6a8d
Reliable 3-Pin Blue Wire Mount Socket Connector for secure and efficient wiring connections.
Regular price
$2.10
Regular price
Sale price
$2.10
Unit price
per
Initiate Order
High-Quality 3-Pin Blue Wire Mount Socket Connector
$2.10
Quantity: 1
Claim Your Seller Account
High-Quality 3-Pin Blue Wire Mount Socket Connector
$2.10
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The High-Quality 3-Pin Blue Wire Mount Socket Connector is a versatile solution designed for optimal connectivity. With a robust Terminal Material of C5210 (Gold 0.2 μm) and Body Material of Polycarbonate/Acrylonitrile Butadiene Styrene (ABS) (UL94V-0), this Sensor Connector ensures reliable performance. It meets Maximum Alternating Current (AC)/Direct Current (DC) Voltage of ~250 V, with a Maximum Rated Current of 3.0 A. Offering secure Terminal Retention and a Nominal Cross Section Area of 0.32 to 0.5 mm², this connector is a dependable choice for various wiring needs.
Product Specifications
Specifications Body Material
Polycarbonate/Acrylonitrile Butadiene Styrene (ABS) (UL94V-0)
Specifications Case Material
Polycarbonate (UL94-V0)
Specifications Color
Blue
Specifications Connector Type
Wire Mount Socket
Specifications Cover Color
Blue
Specifications Cover Diameter
1.2 to 1.6 mm
Specifications List Price
2.10 USD
Specifications Maximum Alternating Current Acdirect Current Dc V
~250 V
Specifications Maximum Insertion Per Pin
1.96 N | 200 gf
Specifications Maximum Rated Current
3.0 A
Specifications Minimum Extraction Per Pin
0.49 N | 50 gf
Specifications Minimum Terminal Retention
1.4 kgf
Specifications Nominal Cross Section Area
0.32 to 0.5 mm²
Specifications Number Of Pins
3
Specifications Terminal Material
C5210 (Gold 0.2 μm)
Specifications Type
Sensor Connector
Specifications Weight
0.56 lb
Specifications Wire Cross Sectional Area
0.32 to 0.5 mm²
Specifications Wire Size
22-20 AWG
