High-Quality Clear Threaded Sight Glass - 2-11.5 NPT, Nickel Plated

Name: High-Quality Clear Threaded Sight Glass - 2-11.5 NPT, Nickel Plated
Brand: Pegasus Glass
SKU: SIG-80a815
Price: 29.99 USD
Availability: OutOfStock

SKU:SIG-80a815

Premium clear threaded sight glass for liquid level monitoring with 2-11.5 NPT and nickel-plated finish. Ideal for power transmissions, gear boxes, and more.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Experience top-tier performance with our hermetically sealed clear threaded sight glass. Designed for liquid level monitoring in power transmissions, gear boxes, reservoirs, and pumps, these sight glasses offer unmatched durability and precision. With a thread size of 2-11.5 NPT, a lens diameter of 1.875 inches, and a design pressure of 1000 psig, you can trust in the reliability of our sight glass under extreme conditions. Nickel plated for enhanced longevity and resistance to corrosion, this sight glass delivers exceptional value and performance. Maintain visibility and accuracy with a maximum operating temperature of 500 °F, meeting the stringent demands of industrial applications.

Product Specifications

Applications 0

Power TransmissionsGear BoxesReservoirsPumps etc

Note For Design Pressure 0

Actual working pressure to which these units are subjected should be chosen by the user to assure a proper margin of safety. Maximum operating temperature 500 ÂºF

Specifications Design Pressure

1000 psig

Specifications Finish

Nickel Plated

Specifications Hex Size

2 1/2 in

Specifications Length

1 9/32 in

Specifications Lens Diameter

1.875 in

Specifications Maximum Operating Temperature

500 ÂºF

Specifications Thread Size Npt

2 - 11.5

High-Quality Clear Threaded Sight Glass - 2-11.5 NPT, Nickel Plated
