High Strength UNF/UNC Threaded Shaft Collar Clamp
High Strength UNF/UNC Threaded Shaft Collar Clamp
SKU:THR-909c7b
Precision machined UNF/UNC threaded shaft collar with high clamping power & black oxide finish
Regular price
$47.33
Regular price
Sale price
$47.33
Unit price
per
Initiate Order
High Strength UNF/UNC Threaded Shaft Collar Clamp
$47.33
Quantity: 1
Claim Your Seller Account
High Strength UNF/UNC Threaded Shaft Collar Clamp
$47.33
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The High Strength UNF/UNC Threaded Shaft Collar Clamp is a precision machined, non-marring one-piece split clamp-type collar designed to fit standard UNF/UNC threaded shafts. Offering superior holding power over set-screw type collars, this collar features an easy-to-adjust design with high clamping force, ensuring secure shaft attachment. Made from durable steel with a black oxide finish, this collar is available in High Strength style, meeting RoHS2 and REACH compliance. With dimensions of 3.500 inches outside diameter and a 2 1/4-12 threaded bore size, this collar is ideal for various industrial applications.
Product Specifications
Dimensional Attributes Outside Diameter
3.500 in
Dimensional Attributes Recessed Screw
Yes
Dimensional Attributes Screw Material
Alloy Steel
Dimensional Attributes Screw Size
5/16-24
Dimensional Attributes Threaded Bore Size
2 1/4-12
Dimensional Attributes Width
0.625 in
Specifications Alloy
1215
Specifications Approximate Weight
0.95 lb
Specifications Country Of Origin
USA
Specifications Finish
Black Oxide
Specifications List Price
47.33 USD
Specifications Material
Steel
Specifications Part Number
3L204
Specifications Reach Compliant
Yes
Specifications Rohs2 Compliant
Yes
Specifications Series
Signature
Specifications Type
High Strength
Specifications Upc Code
662786011283
