High-Temp Graphite Gasket - Tang Inserted
High-Temp Graphite Gasket - Tang Inserted
SKU:FLE-475cc0
High-temp graphite gasket for critical applications, with superior sealing and temperature resistance.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
High-Temp Graphite Gasket - Tang Inserted
$29.99
Quantity: 1
Claim Your Seller Account
High-Temp Graphite Gasket - Tang Inserted
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Tang Inserted Flexible Graphite Gasket is designed for critical applications, ensuring a perfect fit to flange faces. With a temperature range of -380 to 900 °F, this gasket is resistant to organic and inorganic acids, solvents, and more. Its impermeability to gases and fluids, along with corrosion resistance, makes it ideal for sealing high-temperature valves, shafts, and flanges. Although not suitable for strong oxidizing compounds, it excels in various industrial settings demanding reliability and efficiency.
Product Specifications
Specifications Applications
Ultimate material for critical applications. The gasket self-forms during torque down of assembly thus ensuring a perfect fit to flange faces:Resistant to organic, inorganic acids, solvents, hot wax and oils | Impermeable to gases and fluids, corrosion resistant | Excellent for sealing high temperature valves, shafts, and flanges, high thermal conductivityExceptions are Strong oxidizing compounds such as:Concentrated nitric acids, high concentrated sulphuric acids, chromium (VI) and permanganate solutions,
Specifications Available Thickness
1/16 in | 1/8 in | 1/32 in | 1/64 in
Specifications Sheet Size
39.4 x 39.4 in
Specifications Temperature Range
-380 to 900 ºF | -229 to 482 ºC
