High Temp Push-Pull Cable Assembly

High Temp Push-Pull Cable Assembly

SKU:PUS-f54ba9

High Temp Push-Pull Cable Assembly with stainless steel support tubes and end rods, ideal for high-temperature environments.

Regular price $49.99
Regular price Sale price $49.99
Sale

Initiate Order

High Temp Push-Pull Cable Assembly

High Temp Push-Pull Cable Assembly

$49.99

Quantity: 1

Claim Your Seller Account

High Temp Push-Pull Cable Assembly

High Temp Push-Pull Cable Assembly

$49.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The High Temp Push-Pull Cable Assembly is designed for superior performance in high-temperature environments, with stainless steel support tubes and end rods ensuring durability and precision. Featuring a TFE liner, Santoprene cover, and a maximum operating temperature of 310°F, this cable exceeds industry standards for heat resistance. With options for various cable travel lengths and seal types, this cable assembly offers versatility and reliability. Ideal for industrial applications requiring robust, high-temperature cable control solutions.

Product Specifications

Specifications Cable Travel
1 " | 2 " | 3 " | 4 " | 5 " | 6 "
Specifications Conduit Cap Types Options Gg Tg Tt Cc
T - Threaded Swivel/T - Threaded Swivel
Specifications Conduit Description
High Temp: Includes binder wire, TFE liner, Santoprene cover, rated to 310 deg. F. (the other conduits max out as 230 deg. F).
Specifications End Rod Thread Size I
10-32
Specifications Seal Options
6
Specifications Suffix Letters For Additional Features
A - Combination of N and W | M - Metric End Rods (optional) | N - End Rod Jam Nuts (2 each) | P - Stamp with Customer Part Number | S - Stamp with Cablecraft and Customer Part Number | W - Extra Shakeproof Washers on Conduit Ends
CAGE
0T9L4
NAICS
332510
PSC
4030
