High Temp Push-Pull Standard Cable

High Temp Push-Pull Standard Cable

SKU:PUS-5f9acb

Explore the High Temp Push-Pull Standard Cable for superior heat resistance and versatile customization options.

Regular price $39.99
Regular price Sale price $39.99
Sale

Initiate Order

High Temp Push-Pull Standard Cable

High Temp Push-Pull Standard Cable

$39.99

Quantity: 1

Claim Your Seller Account

High Temp Push-Pull Standard Cable

High Temp Push-Pull Standard Cable

$39.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The High Temp Push-Pull Standard Cable is an essential component of Push-Pull Controls, meticulously crafted with Stainless Steel Support Tubes, End Rods, Conduit Caps, and Innermember Armor. Designed for durability and reliability, this cable incorporates a High Temp Conduit featuring a TFE liner, Santoprene cover, binder wire, and a remarkable temperature rating up to 310 deg. F, exceeding industry standards for heat resistance. With various seal options, end rod thread size of 10-32, and conduit cap types for versatile applications, this cable ensures optimal performance and longevity. The suffix letters allow for customization, including metric end rods, jam nuts, stamping options, and extra shakeproof washers, catering to diverse requirements.

Product Specifications

Specifications Cable Travel
1 " | 2 " | 3 " | 4 " | 5 " | 6 "
Specifications Conduit Cap Types Options Gg Tg Tt Cc
G - Grooved Swivel/G - Grooved Swivel
Specifications Conduit Description
High Temp: Includes binder wire, TFE liner, Santoprene cover, rated to 310 deg. F. (the other conduits max out as 230 deg. F).
Specifications End Rod Thread Size I
10-32
Specifications Seal Options
6
Specifications Suffix Letters For Additional Features
A - Combination of N and W | M - Metric End Rods (optional) | N - End Rod Jam Nuts (2 each) | P - Stamp with Customer Part Number | S - Stamp with Cablecraft and Customer Part Number | W - Extra Shakeproof Washers on Conduit Ends
CAGE
0T9L4
NAICS
332510
PSC
4030
