High Temp Push-Pull Standard Cable

High Temp Push-Pull Standard Cable

SKU:PUS-1607a1

High Temp Push-Pull Standard Cable with stainless steel components, High Temp conduit, superior temperature rating, and customizable features for precision control.

Regular price $29.99
Regular price Sale price $29.99
Sale

Initiate Order

High Temp Push-Pull Standard Cable

High Temp Push-Pull Standard Cable

$29.99

Quantity: 1

Claim Your Seller Account

High Temp Push-Pull Standard Cable

High Temp Push-Pull Standard Cable

$29.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The High Temp Push-Pull Standard Cable is meticulously crafted with stainless steel support tubes, end rods, and conduit caps, ensuring durability and high-temperature resilience. Featuring a High Temp conduit with binder wire, TFE liner, and Santoprene cover, this cable is rated up to 310°F, surpassing other conduits. Seal Options: 6. End Rod Thread Size: 10-32. Conduit Cap Types: Threaded Swivel/T. Available in various Cable Travel lengths for versatile applications. Choose from optional suffix letters for extra features tailored to your needs, including stamps with custom part numbers and extra shakeproof washers. Ideal for demanding environments requiring high-performance push-pull controls.

Product Specifications

Specifications Cable Travel
1 " | 2 " | 3 " | 4 " | 5 " | 6 "
Specifications Conduit Cap Types Options Gg Tg Tt Cc
T - Threaded Swivel/T - Threaded Swivel
Specifications Conduit Description
High Temp: Includes binder wire, TFE liner, Santoprene cover, rated to 310 deg. F. (the other conduits max out as 230 deg. F).
Specifications End Rod Thread Size I
10-32
Specifications Seal Options
6
Specifications Suffix Letters For Additional Features
A - Combination of N and W | M - Metric End Rods (optional) | N - End Rod Jam Nuts (2 each) | P - Stamp with Customer Part Number | S - Stamp with Cablecraft and Customer Part Number | W - Extra Shakeproof Washers on Conduit Ends
CAGE
0T9L4
NAICS
332510
PSC
4030
