High Temp Push-Pull Standard Cable

High Temp Push-Pull Standard Cable

SKU:PUS-329fa7

High Temp Push-Pull Cable with stainless steel construction and rated up to 310°F. Precision control with multiple seal options and customizable features.

Regular price $39.99
Regular price Sale price $39.99
Sale

Initiate Order

High Temp Push-Pull Standard Cable

High Temp Push-Pull Standard Cable

$39.99

Quantity: 1

Claim Your Seller Account

High Temp Push-Pull Standard Cable

High Temp Push-Pull Standard Cable

$39.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The High Temp Push-Pull Standard Cable is engineered with stainless steel support tubes, end rods, and conduit caps for durability and reliability in demanding environments. Featuring a High Temp conduit that includes binder wire, TFE liner, and a Santoprene cover, this cable is rated up to 310°F, surpassing industry standards. With multiple seal options, grooved swivel conduit cap types, and a variety of cable travel lengths, this cable ensures precision control and flexibility. Additional features like metric end rods, end rod jam nuts, and customizable stamping options make it a versatile solution for diverse applications.

Product Specifications

Specifications Cable Travel
1 " | 2 " | 3 " | 4 " | 5 " | 6 "
Specifications Conduit Cap Types Options Gg Tg Tt Cc
G - Grooved Swivel/G - Grooved Swivel
Specifications Conduit Description
High Temp: Includes binder wire, TFE liner, Santoprene cover, rated to 310 deg. F. (the other conduits max out as 230 deg. F).
Specifications End Rod Thread Size M
M5 x 0.8
Specifications Seal Options
6
Specifications Suffix Letters For Additional Features
A - Combination of N and W | M - Metric End Rods (optional) | N - End Rod Jam Nuts (2 each) | P - Stamp with Customer Part Number | S - Stamp with Cablecraft and Customer Part Number | W - Extra Shakeproof Washers on Conduit Ends
CAGE
0T9L4
NAICS
332510
PSC
4030
