High-Temperature Flexible Graphite Gasket
High-Temperature Flexible Graphite Gasket
SKU:FLE-f4f1f1
Ultimate sealing solution for high-temp applications, self-forming design, superior impermeability & resistance to corrosive substances.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
High-Temperature Flexible Graphite Gasket
$29.99
Quantity: 1
Claim Your Seller Account
High-Temperature Flexible Graphite Gasket
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The High-Temperature Flexible Graphite Gasket is a premium sealing solution designed to excel in critical applications. With a temperature range of -380 to 900 °F, this gasket is ideal for high-temperature valves, shafts, and flanges. Its self-forming nature ensures a perfect fit, while its impermeability to gases and fluids, along with its corrosion resistance, make it a reliable choice. Resistant to organic and inorganic acids, solvents, and more, this gasket meets the stringent requirements of industrial settings.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Additional Note
60 x 60 Sheet Size for 1/8 Inch (in) Thick Sheet
Specifications Applications
Ultimate material for critical applications. The gasket self-forms during torque down of assembly thus ensuring a perfect fit to flange faces:Resistant to organic, inorganic acids, solvents, hot wax and oils | Impermeable to gases and fluids, corrosion resistant | Excellent for sealing high temperature valves, shafts, and flanges, high thermal conductivityExceptions are Strong oxidizing compounds such as:Concentrated nitric acids, high concentrated sulphuric acids, chromium (VI) and permanganate solutions,
Specifications Available Thickness
1/16 in | 1/8 in | 1/32 in | 1/64 in
Specifications Sheet Size
39.4 x 39.4 in | 60 x 60 in
Specifications Temperature Range
-380 to 900 ºF | -229 to 482 ºC
