High Thermal Conductive Silicone RTV-710 WE
High Thermal Conductive Silicone RTV-710 WE
SKU:RTV-d3e826
Highly efficient flame retardant silicone with superior thermal conductivity and heat resistance. Ideal for potting and encapsulation applications.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
High Thermal Conductive Silicone RTV-710 WE
$39.99
Quantity: 1
Claim Your Seller Account
High Thermal Conductive Silicone RTV-710 WE
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Explore the RTV-710 WE High Thermally Conductive Silicone, a flame retardant addition cure silicone rubber ideal for commercial potting and encapsulation with high thermal conductivity and excellent heat resistance. This General Purpose Silicone boasts a Dielectric Strength of 450 V/mil, low shrinkage at 0.1%, and impressive Tensile Strength of 650 psi. With a service temperature range of -54 to 260 °C and thermal conductivity of 10 BTU-in/(ft2)(hr)(°F), it meets demanding industrial requirements.
Product Specifications
Cure Schedule 0
1 hour at 150 °F | 2 hours at 100 °F | 24 hours at room temperature | Pot Life and cure is dependent on temperature
Properties Coefficient Of Thermal Expansion
17 x 10-5 ºC
Properties Color
White (Part A & B)
Properties Dielectric Constant
3.4
Properties Dielectric Frequency
100 Hz
Properties Dissipation Factor
0.001
Properties Dissipation Frequency
60 Hz
Properties Ideal Conditions
40 to 60 % Relative Humidity | 68 to 78 °F (20 to 26 °C)
Properties Mix Ratio By Volume
1:1
Properties Pot Life At 72 F
2700 min
Properties Service Temperature Range
-54 to 260 ºC
Properties Tear Strength Die B
28 lb/in
Properties Thermal Conductivity
10 BTU-in/(ft2)(hr)(°F)
Properties Viscosity Cps
20,000 (Part A) | 25,000 (Part B)
Properties Volume Resistivity
1 x 1014 ohm-cm
Specifications Dielectric Strength
450 V/mil
Specifications Linear Shrinkage
0.1 %
Specifications Mixed Viscosity
20,000 cps
Specifications Shelf Life At 72 F
12 m
Specifications Shore A Hardness
70 duro
Specifications Specific Gravity
2.22 | 2.22 (Part A) | 2.25 | 2.25 (Part B)
Specifications Tensile Elongation
70 %
Specifications Tensile Strength
650 psi
Specifications Type
General Purpose Silicone
Use Instructions 0
Pre mix RTV-710 WE thoroughly. Weigh out the required amount of Part A and add the required amount of Part B. Mix thoroughly scraping both the bottom and sides of the mixing container. Evacuate under vacuum or let sit for 1 hour to facilitate air release if desired, and then apply.
