High Torque Double Shaft Stepper Motor (1.8 Degree/Step) - KA50HM2-501
High Torque Double Shaft Stepper Motor (1.8 Degree/Step) - KA50HM2-501
SKU:STE-9970b7
Precision and reliability in a compact design with high torque, low vibration, and silent operation.
Regular price
$79.99
Regular price
Sale price
$79.99
Unit price
per
Initiate Order
High Torque Double Shaft Stepper Motor (1.8 Degree/Step) - KA50HM2-501
$79.99
Quantity: 1
Claim Your Seller Account
High Torque Double Shaft Stepper Motor (1.8 Degree/Step) - KA50HM2-501
$79.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The KA50 Series Motor with D-Cut Double Shaft is designed for precision and reliability in a compact NEMA 17 frame size. With a high holding torque of 31 oz·in, low detent torque, and silent operation, this stepper motor ensures high position accuracy and low vibration. Employing advanced three dimensional magnetic field analysis, it offers improved motor performance and the best magnetic balance. Ideal for industrial automation, robotics, and CNC machinery.
Product Specifications
Additional Information 0
Explanation of Dynamic Torque Curves
Customize 0
Custom Designs
Dimensions 0
Outline | Outline
Specifications Current Per Phase
2.0 A
Specifications Detent Torque
1.7 oz·in | 12 mN·m
Specifications Holding Torque
31 oz·in | 216 mN·m
Specifications Inductance Per Phase
0.9 mH
Specifications L
1.38 in | 35.0 mm
Specifications Motor Frame Size
NEMA 17
Specifications Note
The basic motor characteristics, connection diagrams, and accessories (lead connectors) conform to the standard specifications.
Specifications Product Type
Stepper Motor
Specifications Reference Part Number
KA50HM2-501
Specifications Resistance Per Phase
1.04 Ω
Specifications Rotor Inertia
50 B·cm² | 0.3 oz·in²
Specifications Series
2 Phase Round KA
Specifications Shaft Specification
Double Shaft
Specifications Step Angle
1.8 deg./step
Specifications Type
KA Series Motors with D-Cut Double Shaft Motors (0.9 / 1.8 Degree/Step) - NEMA 17 / 23
Specifications Voltage Per Phase
2.08 V
Specifications Weight
230 g | 0.5 lb
Specifications Winding Method
Unipolar
Torque Curve 0
KA50HM2-501 ST CURVE.jpg
