High Voltage Ceramic Capacitors - HT57 Series, 300 pF, 15 kV
High Voltage Ceramic Capacitors - HT57 Series, 300 pF, 15 kV
SKU:CER-5df2cd
High-performance 300 pF ceramic capacitors with 15 kV max voltage for industrial use.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
High Voltage Ceramic Capacitors - HT57 Series, 300 pF, 15 kV
$29.99
Quantity: 1
Claim Your Seller Account
High Voltage Ceramic Capacitors - HT57 Series, 300 pF, 15 kV
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The HT57 Series Ceramic Capacitors offer unmatched performance in high-voltage applications. With a capacitance of 300 pF and a maximum voltage of 15 kV, these capacitors ensure reliable and efficient operation. The N3300 dielectric and robust construction provide exceptional durability, making them ideal for industrial and institutional settings. Designed for precision, these capacitors deliver a frequency range from 0.165 MHz to 0.742 MHz with a maximum RMS current of 7.00 A. The 10-32 thread ensures easy installation, meeting the stringent requirements of government and institutional procurement standards.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Cap
300 pF
Specifications Dielectric Tc
N3300
Specifications Fh
0.742 MHz
Specifications Fl
0.165 MHz
Specifications Imax Rms
7.00 A
Specifications Smax
35 kV·A
Specifications Thread
10-32
Specifications Vmax Dc
15 kV
