Experience unrivaled reliability with our High Voltage Coaxial Pigtail Cable Assembly from the renowned Series 600 line. Built to withstand extreme conditions, this assembly is ideal for Aerospace/Defense and commercial applications. With a voltage rating of 5 kVDC and altitude tolerance up to 70,000 ft., this miniature connector sets the standard for performance and durability. The Brass coupling nut with Gold Plating ensures secure connections, while the BeCu contact material with Gold finish guarantees superior conductivity. Trust in our Single-Ended Receptacle Cable Assembly for seamless integration and unmatched quality.
Product Specifications
Body Properties Coupling Nut Finish
Gold Plated
Body Properties Coupling Nut Material
Brass
Contact Properties Contact Finish
Gold
Contact Properties Contact Material
BeCu
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Single-Ended Receptacle Cable Assembly
Specifications Coupling Style
Threaded
Specifications Current Rating
1 Amp
Specifications End 1
1674528
Specifications Export Classification
TBD
Specifications Insulator Material
Plastic
Specifications Lock Wire Holes In Coupling Nut
No
Specifications Mating Compatibility
Mates all Series 600 plug assemblies
Specifications Operating Temperature
-55 to 125 ºC
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
No
Specifications Series
600
Specifications Standardnon Standard
Standard Part
Specifications Test Voltage
7.5 kVDC at 70,000 ft. (simulated) at ambient temperature
Specifications Voltage Rating
5 kVDC
